AVS Electronics CAPTURE 8 - Page 54

- 54 -
Sound level
1 (1 . . 8)
R & G Led pulses
Status
Sound level: there is a choice of 8 tones. The values are relative to the sound level of both the Main Sound and the
Alternative Sound. 1 is the Maximum and 8 is the Minimum.
Max time alarm (minutes): The values are relative to the sound level of both the Main Sound and the Alternative Sound
R & G Led pulses: The value set is relative to both the functioning of the Red LED and that for the Green LED:
Status: the LEDs are activated with fixed light at the unbalancing of the relative input and
deactivated at the rebalancing of the relative input
Follows Flash: the LEDs are activated with a cadence similar to that of the FLASH at the
unbalancing of the relative input and deactivated at the rebalancing of the relative input
5 fast pulses: the LEDs emit 5 quick flashes at the unbalancing of the relative input and de-
activated at the rebalancing of the relative input
1 pulse: the LEDs are activated with fixed light for approximately one second at the unbalancing
of the relative input and remain inhibited at the rebalancing of the relative input
Unb = 5fp. Bal = 1p.: the LEDs emit 5 quick flashes at the unbalancing of the relative input
and are activated with a fixed light for approximately one second at the rebalancing of the
relative input
R=blnk+Fl. V=st.:the Red LED emit quick flashes at the unbalancing of the relative input and
slowly at the rebalancing ; the FLASH emit few quick flashes at the unbalancing of STC and
one slowly at the rebalancing; the Green LED is a “STATUS”
Press (CLR) to vary
Press (ENT) to conrm
Press () or () to move
Press (ESC) to go back
Sirens
Max time alarm
3 (1 . . 8)
to following
page
from previus
page
