ﻖﺤﻠﻤﻟا6 ﻦﻳﻮﻜﺗ PIN
67
• زاﺮﻄﺑ صﺎﺧ4 CH
راﺬﻧﻹا ةرﺎﻔﺻ:
ةﺪﺣو ﻞﻴﻐﺸﺗ ﻢﺘﻳ ﺎﻣﺪﻨﻋوDVRﺔﻄﺳاﻮﺑ ﻞﺼﺘﻳ ،ﺔآﺮﺤﻟا وأ ﻪﺒﻨﻤﻟا
COM ﻊﻣ NO راﺪﺻإ ﻲﻓ حﺎﺒﺼﻤﻟا ﻊﻣ راﺬﻧﻹا ةرﺎﻔﺻ أﺪﺒﺗو ،
ﺾﻴﻣﻮﻟاو تﻮﺼﻟا.
* ﻞﺻﻮﻣ D-Sub يرﺎﻴﺘﺧا ﻩﻼﻋأ ضوﺮﻌﻤﻟا . .
ﻲﺴﻴﻃﺎﻨﻐﻤﻟا لﺎﺼﺗﻻا:
ﻞﻴﻐﺸﺗ ﻢﺘﻳ ﻢﺛ ،ﻪﺒﻨﻤﻟا قﻼﻃإ ﻢﺘﻴﺳ ،ﻲﺴﻴﻃﺎﻨﻐﻤﻟا لﺎﺼﺗﻻا ﺢﺘﻓ ﻢﺘﻳ ﺎﻣﺪﻨﻋ
ﻞﻴﺠﺴﺘﻟا.
PIN ﺔﻔﻴﻇﻮﻟا ﻒﺻﻮﻟا
1~4
ﻪﺒﻨﻤﻟا ﻞﺧد
ﻪﺒﻨﻤﻟا ﻞﺧد ﻞﺻو)PIN 1-4 ( ﻞﺻﻮﻣوGND) PIN 5 (كﻼﺳﻷا ماﺪﺨﺘﺳﺎﺑ . ،ﻪﺒﻨﻤﻟا قﻼﻃإ دﺮﺠﻤﺑو
ةﺪﺣو أﺪﺒﺘﺳDVRسﺮﺠﻟا ﻞﻴﻐﺸﺗ ﻢﺘﻴﺳو ،ﻞﻴﺠﺴﺘﻟا ﻲﻓ .
PIN ﻪﺒﻨﻤﻟا ﺔﻘﻓاﻮﺘﻣ ﻮﻳﺪﻴﻓ ةﺎﻨﻗ
PIN 1 1 ةﺎﻨﻘﻟا1
PIN 2 2 ةﺎﻨﻘﻟا2
PIN 3 3 ةﺎﻨﻘﻟا3
PIN 4 4 ةﺎﻨﻘﻟا4
5
GND ضرﻷا
6
ﻲﺟرﺎﺨﻟا ﻪﺒﻨﻤﻟاCOM
،يدﺎﻌﻟا ﻞﻴﻐﺸﺘﻟا ﺪﻨﻋ ﻞﺼﻔﺗ COM ماﺪﺨﺘﺳﺎﺑ NO ﻞﺼﺘﺗ ،ﻪﺒﻨﻣ يأ قﻼﻃإ ﻢﺘﻳ ﺎﻣﺪﻨﻋ ﻦﻜﻟ ،COM
ماﺪﺨﺘﺳﺎﺑNO.
ﻪﺒﺘﻧا : ﻦﻣ ﻞﻗأ ﻲﺑﺮﻬﻜﻟا ﺪﻬﺠﻟا ﺪﻴﻴﻘﺗ24 يأ ﺖﻟﻮﻓ 1ﺮﻤﺘﺴﻤﻟا رﺎﻴﺘﻠﻟ ﺮﻴﺒﻣأ .
7
ﻲﺟرﺎﺨﻟا ﻪﻴﺒﻨﺘﻟا ﻢﻗر
ﻞﺼﻔﺗ ،يدﺎﻌﻟا ﻞﻴﻐﺸﺘﻟا ﺪﻨﻋCOM ماﺪﺨﺘﺳﺎﺑ NO ﻞﺼﺘﺗ ،ﻪﺒﻨﻣ يأ قﻼﻃإ ﻢﺘﻳ ﺎﻣﺪﻨﻋ ﻦﻜﻟ ،COM
ماﺪﺨﺘﺳﺎﺑNO.
ﻪﺒﺘﻧا : ﻦﻣ ﻞﻗأ ﻲﺑﺮﻬﻜﻟا ﺪﻬﺠﻟا ﺪﻴﻴﻘﺗ24 يأ ﺖﻟﻮﻓ 1ﺮﻤﺘﺴﻤﻟا رﺎﻴﺘﻠﻟ ﺮﻴﺒﻣأ .
8
RS485-A
9
RS485-B
10~11
GND
ضرﻷا
ﻞﻴﺻﻮﺗ ﻖﻴﺒﻄﺗPIN
ﻲﺴﻴﻃﺎﻨﻐﻣ ﻞﻴﺻﻮﺗ
راﺬﻧﻹا ةرﺎﻔﺻ
ـﻟ مﺎﺤﻠﻟا ﺐﻧﺎﺟDSUB
ﻦﻣ نﻮﻜﻤﻟا9 PIN
ءيﺎﻬﻣ
ﺔﻗﺎﻄﻟا
