22 WOLF NETWORK CONFIGURATION IMPORT / EXPORT FILE
In this part of the control software, you will see various parameters. The first section, shown below, specifies the file
name, author, date/time of changes and any notes that may be included for the device in question.
;****************************************************************************************
;* WOLF NETWORK CONFIGURATION IMPORT/EXPORT FILE
;*
;* FILE : untitled.tcf
;*
;* AUTHOR:
;*
;* DATE : 08/08/2011
;* TIME : 16:10:30
;*
;* NOTES :
;*
;****************************************************************************************
The lower section, meanwhile, shows the Wolf Network operating values (the settable values are discussed in the next
section):
N°
Parameter name/command
Description
Notes
[GENERAL_SETTINGS]
Menu name and description
01
TARGET_MODEL=Wolf_Slave
Name of connected device
Non-editable field
02
FIRMWARE_VERSION=2.0
Firmware release installed on
“TARGET_MODEL”
03
TARGET_NAME="WF3-Axel"
Name of TARGET_MODEL device which will
appear in the software and on the front panel
(INFO & ALARMS) of the Wolf Network
04
EXTENDED_TARGET_NAME="WF3-Sede Axel"
Full name of TARGET_MODEL device which
will appear in the software and on the front
panel (INFO & ALARMS) of the Wolf Network
05
USER_NAME=""
User name which will be requested when
accessing the Wolf Network device via Remoter
If the field is empty, this is not
required
06
PASSWORD=""
Password which will be requested when
accessing the Wolf Network device via Remoter
If the field is empty, this is not
required
07
WEB_PASSWORD=""
Password which will be requested when
accessing the Wolf Network device via
webpage.
If the field is empty, this is not
required
08
KEYBOARD_LOCK=Unlocked
This parameter allows you to lock the Wolf
Network device‟s front keypad.
When locked, the keypad cannot be
used.
09
SNMP_PRIVATE_ACCESS_PASSWORD="private"
Password for writing via SNMP protocol (default
setting is "private”)
10
SERIALS_SPEED=38400_Baud
Speed setting for all three serial ports. This
parameter is unique.
Default setting is 38400_Baud
11
SERIAL_1_MODE=Bidirectional
RS232-1 port connection mode
Monodirectional and Bidirectional
12
SERIAL_2_MODE=Bidirectional
Rs232-2 port connection mode
Monodirectional and Bidirectional
13
SERIAL_3_MODE=Uecp
Rs232-3 port connection mode
14
ANALOGIC_OUT_LEVEL=+3.5dB
Analog Output Level Setting
15
DIGITAL_INTERFACE=On
AES3/EBU output enable
16
DIGITAL_OUT_LEVEL=-21.7dBFs
Digital output level
17
DIGITAL_OUT_RATE=44.1KHz
Digital output sample rate
18
MASK_ALL_ALARMS=Off
This enables or disables alarm reporting by the
Wolf device
19
WEB_REFRESH_SPEED=Normal
Wolf Web page refresh speed setting
20
NETWORK_POSITION=0
21
NETWORK_POSITION_TIME=0SEC
22
PILOT_PROT_MEASURE=On
Pilot Protection measurement enable
