25 WOLF MEASUREMENT DATABASE (MEASURE DB)
This panel displays a series of parameters measured by the Wolf Network. This section is basically divided into two
columns, with the Current Time Slot Measurement on the right-hand side and the Last Error Slot Measurement Module
on the left. The Current Time Slot Measurement Module section provides measurements taken at a given slot time,
which is normally every 10 minutes. The following image shows that the slot started on 17/08/2011 at 16:10 and at ended
at 16:20 and that there are Failure statuses (a series of errors in a slot that have invalidated the measurement).
The right-hand section of the panel contains the Last Error Slot Measures.
