AXISA8207-VEMkIINetworkVideoDoorStation
Additionalsettings
4.EntertheIPaddressforthedoorcontroller.
5.Enterthecredentialsforthedoorcontroller.
6.ClickConnect.
7.Selecttheentrancereaderfortheappropriatedoor.
8.ClickSave.
Setupascardreader-wiredconnection
Tousethedoorstationasacardreader,youmustconnectittoadoorcontroller.Thedoorcontrollerstoresallcredentialsandkeeps
trackofwhoisallowedthroughthedoor.Inthisexample,weconnectthedeviceswithwires,weusetheWiegandprotocol,activate
thebeeperanduseoneI/OportfortheLED.Wealsomodifytheallowedcardtypes.
Important
UseI/Oportsthatarenotalreadyinuse.IfyouuseI/Oportsalreadyinuse,anyeventscreatedfortheseportswillstop
working.
Beforeyoustart
•Connectthedoorstationtoadoorcontroller,seeElectricalWiringDrawings.
•Congurethedoorcontroller’shardware,usingtheWiegandprotocolforthereader.Seethedoorcontroller’suser
manualforinstructions.
Setupthedoorstationasacardreader
1.GotoReader>Readerprotocol.
2.SelectWiegand.
3.TurnonBeeper.
4.UnderInputforbeeper,selectI3.
5.InInputsusedforLEDcontrol,select1.
6.UnderInputforLED1,selectI1.
7.Selectwhatcolorstouseforeachstate.
8.UnderKeypressformat,selectFourBit.
9.ClickSave.
10.GotoReader>Chiptypesandactivatethechiptypesyouwanttouse.
Note
Youcankeepthedefaultsetofchiptypesbutwerecommendmodifyingthelistaccordingtoyourspecicneeds.
11.ClickAdddatasettospecifythedatasetsforthedifferentchiptypes.
12.ClickSave.
Useprotecteddataoncardstoincreasesecurity
Toincreasesecurityinyouraccesscontrolsystem,youcanchoosetousesecurecarddatastoredonsometypesofcards.Thedatais
protectedbyasecretkey.Toreadthecarddata,youneedtostorethesecretkeyandotherinformationaboutthecardonthedevice.
1.GotoReader>Chiptypes.
