AXISA9188NetworkI/ORelayModule
RelayJumper
3-pinrelayjumperforenablingpowertoauxiliaryequipmentviathe
Relayconnector.Insertingthejumperbetween12Vor24VtoCOM
causestheinternalvoltagetobeconnectedtotheCOMterminalof
therelay.
•+12V
•RelayCOM
•+24V
FunctionPinNotes
Specications
+12V+12VUsejumpertoconnectpoweroutto
RelayCOM
+12VDC
RelayCOMCOMOutputpowertoauxiliaryequipment
whenjumperisused
+24V+24VUsejumpertoconnectpoweroutto
RelayCOM
+24VDC
12/24VDCOutPowerConnector
3–pinterminalblockfor:
•0VREF
•12VDCOUT
•24VDCOUT
FunctionPinNotes
Specications
0VREF
1
0VDC
12VDCOUT
2
Forpoweringauxiliary
equipment.
SeePowerConsumptiononpage
21
24VDCOUT
3
Forpoweringauxiliary
equipment.
SeePowerConsumptiononpage
21
Important
Therecommendedmaximumcablelengthis30m(98.4ft).
