AXISI8116-ENetworkVideoIntercom
Specifications
ForSDcardrecommendations,seeaxis.com.
microSD,microSDHC,andmicroSDXCLogosaretrademarksofSD-3CLLC.microSD,microSDHC,microSDXCare
trademarksorregisteredtrademarksofSD-3C,LLCintheUnitedStates,othercountriesorboth.
Buttons
Controlbutton
Thecontrolbuttonisusedfor:
•Resettingtheproducttofactorydefaultsettings.SeeResettofactorydefaultsettingsonpage58.
•Connectingtoaone-clickcloudconnection(O3C)serviceovertheinternet.Toconnect,pressandholdthebutton
forabout3secondsuntilthestatusLEDashesgreen.
Connectors
Networkconnector
RJ45EthernetconnectorwithPoweroverEthernet(PoE).
I/O,reader,andrelayconnector
YoucanusethisconnectorforI/Oandrelay,orforreaderconnectivity.
6-pinterminalblock
1
-
2
12V
3
A/IO1
4
B/IO2
5
NO/NC
6
CO
FunctionPinNotes
Specications
DCground
1
0VDC
DCoutput
2
Canbeusedtopowerauxiliaryequipment.
Note:Thispincanonlybeusedaspowerout.
12VDC
I/O:Maxload=50mA
Reader/relay:Maxload=
350mA
I/O:Congurable
(InputorOutput)
Reader:A
3
I/O:Digitalinput–Connecttopin1toactivate,orleaveoating
(unconnected)todeactivate.Digitaloutput–Internallyconnected
topin1(DCground)whenactive,andoating(unconnected)when
inactive.Ifusedwithaninductiveload,e.g.,arelay,connectadiode
inparallelwiththeload,toprotectagainstvoltagetransients.
Reader:RS485–A
I/O:input–0tomax30VDC
output–0tomax30VDC,
opendrain,100mA
