2.Features
1. TFT LCD monitor with wide angle view and high resolution display.
2. NORMAL, MIRROR,FLIP and MIR-FLIP viewing available.
3. Split mode, auto-scan mode and single-display mode available.
4. Auto pairing: Auto pairing happens when camera is activated.
5. Auto dim function available.
6. Full-function remote control.
7. 4 wireless camera input.
8. Multiple video formats: PAL / NTSC.
9. Wide voltage input: 10 - 32V.
10. On-board speaker.
11. Auto switch to the working channel when trigger is activated
12. With touch buttons.
3.Technical Specifications
LCD size 5.6"
Resolution 640 x 3 (RGB) x 480
Contrast 500:1
Brightness 200 cd/m²
Viewing Angle U: 50 / D: 70, R/L: 70
Channel 4 channels
Operating Frequency 2400 - 2483.5 MHz
Receiving Sensitivity -89 dBm
Decompression Form MPEG4
Transmit Output Power 17 dBm
Modulation 2.4G FSK/GFSK
Time Delay 120ms
Transmitting Distance 120 M
System Format PAL / NTSC
Power Supply DC 10-32V
Power Consumption Max. 5W
Loudspeaker 1W/8
Operating temperature -20~+70ºC,RH90%
Storage temperature -30~+80ºC,RH90%
Special Notice
All specifications are subject to change without notice.
