AXISM1033-WNetworkCamera

VideoandAudio

1.GotoVideo&Audio>OverlayImage.

2.ClickBrowseandbrowsetothele.

3.ClickUpload.

4.TheTransparencySettingspageisnowdisplayed:

-Tomakeacolorintheoverlayimagetransparent,selectUsetransparencyandentertheRGBhexadecimalvalue

forthecolor.Example:Tomakewhitetransparent,enter#FFFFFF.

Formoreexamplesofhexadecimalvalues,seetheonlinehelp

-Toscaletheimageautomatically,selectScalewithresolution.Theimagewillbescaleddowntotthe

resolutionusedbytheAxisproduct.

5.ClickSave.

Toselecttheimagetouseasoverlay:

1.GotoVideo&Audio>OverlayImage.

2.SelecttheimagetousefromtheUseoverlayimagelistandclickSave.

Todisplaytheoverlayimage:

1.GotoVideo&Audio>VideoStreamandselecttheImagetab.

2.UnderOverlaySettings,selectIncludeoverlayimageatthecoordinates.

3.Tocontroltheimage’sposition,entertheXandYcoordinates.TheX=0andY=0positionisthetopleftcorner.Ifapartof

theimageispositionedoutsidethevideoimage,theoverlayimagewillbemovedsothatthewholeimageisvisible.

4.ClickSave.

UseOverlayTextinanActionRule

Actionrules,seepage35,candisplayanoverlaytextwhentheruleistriggered.Thetextcanbeusedtoprovideinformationfor

forensicvideoanalysis,notifysurveillanceoperatorsorvalidatetriggersandactionsduringproductinstallationandconguration.

Todisplayoverlaytextwhenanactionruleistriggered,themodier#Dshouldbeusedasdescribedbelow.Whentheruleis

triggered,#Dwillbereplacedbythetextspeciedintheactionrule.

Startbyenablingoverlaytextinthevideostream:

1.GotoVideo&Audio>VideoStreamandselecttheImagetab.

2.UnderOverlaySettings,selectIncludetext.

3.Enterthemodier#Dand,optionally,additionaltextwhichwillbedisplayedalsowhentheactionruleisnotactive.

Createtheactionrule:

1.GotoEvents>ActionRules

2.ClickAddtocreateanewrule.

3.SelectaTriggerand,optionally,aScheduleandAdditionalconditions.Seetheonlinehelpfordetails.

4.FromtheActionslist,selectOverlayText

5.EnterthetexttodisplayintheTexteld.Thisisthetextthat#Dwillbereplacedby.

6.SpecifytheDuration.Thetextcanbedisplayedwhiletheruleisactiveorforaxednumberofseconds.
