Axis M1054 Installation Guide

AXIS M10 Series Page 7
ENGLISH
AXIS M1031-W and AXIS M1054 only
AXIS M1031-W and AXIS M1054 are equipped with the following:
PIR sensor - passive infrared sensor that measures infrared light from
passing objects in its field of view. When configured, the camera can
automatically switch on the light when triggered by the PIR sensor.
Sensitivity range up to 5m (16ft).
Light - the camera can be configured so that the white illumination LED
is triggered by the PIR sensor; this can also be done via the web pages -
Setup > Live View Config > Light buttons. The light is designed for
temporary use and should not be permanently lit.
Microphone/speaker for half duplex audio; full-duplex for AXIS M1054.
For more information see the product’s User’s Manual located on the
Axis web site at www.axis.com or on the Axis Network Video Product CD.

Axis M1054 Specifications

General

Max Resolution	1280x800
Operating Temperature	0 °C to 50 °C (32 °F to 122 °F)
Day/Night	No
Humidity	20-80% RH (non-condensing)
Image Sensor	1/4" progressive scan RGB CMOS
Resolution	1280x800
Lens	2.8 mm, F2.0
Video Compression	H.264, Motion JPEG
Frame Rate	30 fps in all resolutions
Audio	Two-way audio with built-in microphone and speaker
Audio Compression	AAC LC 8/16 kHz, G.711 PCM
Network	10/100 Mbps Ethernet
Power	Power over Ethernet (PoE) IEEE 802.3af
Power Consumption	Max 3.8 W
