Axis M1054 Installation Guide

Page 12 AXIS M10 Series
AXIS Camera Management - multiple cameras/large installations
AXIS Camera Management can automatically discover multiple Axis
devices, show connection status, manage firmware upgrades and set IP
addresses.
Automatic discovery
1. Check that the camera is connected to the network and that power
has been applied.
2. Start AXIS Camera Management. When the camera appears in the
window, right-click the link and select Live View Home Page.
3. See page 13 for instructions on how to set the password.
Assign an IP address in a single device
1. Select AXIS M1011 in AXIS Camera Management and click the
Assign IP button .
2. Select Assign the following IP address and enter the IP address,
subnet mask and default router the device will use.
3. Click the OK button.

Axis M1054 Specifications

General

Max Resolution	1280x800
Operating Temperature	0 °C to 50 °C (32 °F to 122 °F)
Day/Night	No
Humidity	20-80% RH (non-condensing)
Image Sensor	1/4" progressive scan RGB CMOS
Resolution	1280x800
Lens	2.8 mm, F2.0
Video Compression	H.264, Motion JPEG
Frame Rate	30 fps in all resolutions
Audio	Two-way audio with built-in microphone and speaker
Audio Compression	AAC LC 8/16 kHz, G.711 PCM
Network	10/100 Mbps Ethernet
Power	Power over Ethernet (PoE) IEEE 802.3af
Power Consumption	Max 3.8 W
