Connectors
I/OConnector
4–pinterminalblock
1
2 3 4
Foranexamplediagram,seeConnectionDiagramsonpage17.
Func-
tion
P-
i-
n
Notes
Specications
0VDC(-)
1
0VDC
DC
output
2
Canbeusedtopowerauxiliary
equipment.
Note:Thispincanonlybeused
aspowerout.
12VDC
Maxload=15mA
