AXISM11NetworkCameraSeries
ConnectionDiagrams
I/OConnector
1
2
3
4
1
0VDC(-)
2
DCoutput12V,max15mA
3
I/Oconguredasinput
4
I/Oconguredasoutput
17
ENGLISH
