Axis M1124 Installation Guide

AXISM11NetworkCameraSeries
Digital
Input
3
Connecttopin1toactivate,or
leaveoating(unconnected)to
deactivate.
0tomax30VDC
Digital
Output
4
Connectedtopin1
whenactivated,oating
(unconnected)when
deactivated.Ifusedwith
aninductiveload,e.g.arelay,
adiodemustbeconnected
inparallelwiththeload,for
protectionagainstvoltage
transients.
0tomax30VDC,
opendrain,
100mA
PowerConnector
2-pinterminalblockforDCpowerinput.Usea
SafetyExtraLowVoltage(SELV)compliantlimited
powersource(LPS)witheitheraratedoutputpower
limitedto≤100Woraratedoutputcurrentlimited
to≤5A.
16
