Axis M3005-V - Hardware Overview and Initial Access; Hardware Overview and Components

AXISM3005-VNetworkCamera
HardwareOverview
HardwareOverview
2
3
4
5
6
1
1
StatusLED
2
Domecover
3
Controlbutton
4
microSDcardslot
5
Networkconnector(PoE)
6
Focusring
ConnectorsandButtons
Fortechnicalspecications,seepage54.
ControlButton
Forlocationofthecontrolbutton,seeHardwareOverviewonpage7.
Thecontrolbuttonisusedfor:
•EnablingtheFocusAssistant.PressandveryquicklyreleasetheControlbutton.
•Resettingtheproducttofactorydefaultsettings.Seepage49.
•ConnectingtoanAXISVideoHostingSystemservice.Seepage42.Toconnect,pressandholdthebuttonforabout3
secondsuntiltheStatusLEDashesgreen.
•ConnectingtoAXISInternetDynamicDNSService.Seepage42.Toconnect,pressandholdthebuttonforabout3seconds.
LEDIndicators
Note
•TheStatusLEDcanbeconguredtoashwhileaneventisactive.
•TheStatusLEDcanbeconguredtoashforidentifyingtheunit.GotoSetup>SystemOptions>Maintenance.
StatusLED
Indication
Unlit
Connectionandnormaloperation.
GreenShowssteadygreenfor10secondsfornormaloperationafterstartupcompleted.
Amber
Steadyduringstartup.Flashesduringrmwareupgrade.
