Axis M3105-L User Manual

AXISM31Series
Setup
Note
IfyouuseWDR,youmayexperiencesomeWDRartifactsintheimage.
FindoutmoreaboutWDRandhowtouseitataxis.com/web-articles/wdr
Streamingandstorage
Howtochoosevideocompressionformat
Decidingwhichcompressionmethodtochoosedependsonyourviewingrequirements,andonthepropertiesofyournetwork.The
availableoptionsare:
MotionJPEG
MotionJPEGorMJPEGisadigitalvideosequencethatismadeupofaseriesofindividualJPEGimages.Theseimagesarethen
displayedandupdatedataratesufcienttocreateastreamthatshowsconstantlyupdatedmotion.Fortheviewertoperceivemotion
videotheratemustbeatleast16imageframespersecond.Fullmotionvideoisperceivedat30(NTSC)or25(PAL)framespersecond.
TheMotionJPEGstreamusesconsiderableamountsofbandwidth,butprovidesexcellentimagequalityandaccesstoeveryimage
containedinthestream.
H.264orMPEG-4Part10/AVC
Note
H.264isalicensedtechnology.TheAxisproductincludesoneH.264viewingclientlicense.Installingadditionalunlicensed
copiesoftheclientisprohibited.Topurchaseadditionallicenses,contactyourAxisreseller.
H.264can,withoutcompromisingimagequality,reducethesizeofadigitalvideolebymorethan80%comparedtotheMotion
JPEGformatandbyasmuchas50%comparedtotheMPEG-4standard.Thismeansthatlessnetworkbandwidthandstoragespace
arerequiredforavideole.Orseenanotherway,highervideoqualitycanbeachievedforagivenbitrate.
Findoutmoreataxis.com/compression-formats
Howtoreducebandwidthandstorage
Important
Ifyoureducethebandwidthitcanresultinlessdetailsinthepicture.
1.GotoliveviewandselectH.264.
2.GototheStreamtab.
3.Dooneormoreofthefollowing:
-TurnontheZipstreamfunctionalityandselectthedesiredlevel.
-TurnontheGOPandsetahighGOPlengthvalue.
-Increasethecompression.
-TurnonthedynamicFPS.
Howtosetupnetworkstorage
Tostorerecordingsonthenetwork,youneedtosetupnetworkstorage:
1.GotoSettings>System>Storage.
2.ClickSetupunderNetworkstorage.
10

Axis M3105-L Specifications

General

Type	IP security camera
Certification	EN 55022 Class B, EN 55024, IEC 62471, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B, RCM AS/NZS CISPR 22 Class B, KCC KN32 Class B, KN35 IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-78, IEC 60068-2-14, IEC 60068-2-6, IEC 60068-2-27, IEC/EN 60529 IP42, IEC 60721-3-4 Class 3M3 IEC/EN/UL 60950-1
Day/night mode	Yes
Languages support	Multi
Placement supported	-
Connectivity technology	Wired
Sensor type	CMOS
Optical sensor size	1/2.8 \
Lens mount interface	M12
Focus adjustment	2.0
Fixed focal length	2.8 mm
Pan range	-180 - 180 °
White balance	Auto
Tilt angle range	0 - 60 °
Angle of rotation	190 °
Camera shutter speed	1/65000 - 2 s
Minimum illumination	0 lx
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Image quality adjustment	Brightness, Colour depth, Contrast, Sharpness
Video compression formats	AVC, H.264, M-JPEG, MPEG4
Supported graphics resolutions	176 x 120, 1920 x 1080 (HD 1080)
Ethernet LAN (RJ-45) ports	1
Power consumption (max)	6.2 W
Power consumption (typical)	4.2 W
Security algorithms	802.1x RADIUS, HTTPS, SSH, SSL/TLS
Alert notification type	E-mail
Password protection type	User
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet interface type	Fast Ethernet
Supported network protocols	IPv4/v6, HTTP, HTTPS, SSL/TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP, SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH
Form factor	Dome
Mounting type	Ceiling/wall
Product color	White
Housing material	Polymer
Protection features	Dust resistant, Water resistant
International Protection (IP) code	IP42
Built-in HDD	No
Flash memory	256 MB
Internal memory	512 MB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	15 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 85 %
Harmonized System (HS) code	85258900

Weight and Dimensions

Width	100 mm
Height	85 mm
Diameter	360 mm
