AXIS M31 Network Camera Series
Page 9
ENGLIS
H
Hardware overview
Lens holder
180° mark
Optic holder
LED indicat
ors
Lens tool
Black rubber side (for focus adjustment)
Netzwerkk
abel
cable (
0.5m/1.
6ft.)
Optic mount
Use screws
here
to mount camera
Top cover tool
(top of image)
Control button
Transparent side
(for image adj
ustment)
Lens tool
(AXIS M3114-R M12 2MM)
Lens tool for adjusting im
age
Lens tool for adjusting focus
8
10
