Axis M5075-G User Manual

AXISM5075-GPTZCamera
Configureyourdevice
1.GotoVideo>Image>Widedynamicrange.
2.UsetheLocalcontrastslidertoadjusttheamountofWDR.
3.UsetheTonemappingslidertoadjusttheamountofWDR.
4.Ifyoustillhaveproblems,gotoExposureandadjusttheExposurezonetocovertheareaofinterest.
FindoutmoreaboutWDRandhowtouseitataxis.com/web-articles/wdr.
Compensateforbarreldistortion
Barreldistortionisaphenomenonwherestraightlinesappearincreasinglybentclosertotheedgesoftheframe.Awideeldofview
oftencreatesbarreldistortioninanimage.Barreldistortioncorrectioncompensatesforthisdistortion.
Note
Barreldistortioncorrectionaffectstheimageresolutionandeldofview.
1.GotoVideo>Installation>Imagecorrection.
2.TurnonBarreldistortioncorrection(BDC).
Verifythepixelresolution
Toverifythatadenedpartoftheimagecontainsenoughpixelsto,forexample,recognizethefaceofaperson,youcanusethe
pixelcounter.
1.GotoVideo>Imageandclick.
2.Click
forPixelcounter.
3.Inthecamera’sliveview,adjustthesizeandpositionoftherectanglearoundtheareaofinterest,forexamplewhere
youexpectfacestoappear.
Youcanseethenumberofpixelsforeachoftherectangle’ssides,anddecideifthevaluesareenoughforyourneeds.
Hidepartsoftheimagewithprivacymasks
Youcancreateoneorseveralprivacymaskstohidepartsoftheimage.
9

Axis M5075-G Specifications

General

Type	IP security camera
PTZ control	Yes
Auto-tracking	No
Placement supported	Indoor
Connectivity technology	Wireless
Sensor type	CMOS
Optical sensor size	1/2.8 \
Pan speed	179 °/sec
Minimum illumination	0.1 lx
Operating temperature (T-T)	0 - 45 °C
Form factor	Dome
Mounting type	Ceiling
Product color	Black, White
International Protection (IP) code	IP51
Digital zoom	12 x
Optical zoom	5 x
Number of lenses	-
Focal length range	2.2 - 11.0 mm
Power source type	PoE
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Supported graphics resolutions	1920 x 1080 (HD 1080)
Number of cameras	1
Harmonized System (HS) code	85258900
