AXISM5525-EPTZNetworkCamera
Additionalsettings
Useaudiotodeterintruders
Thisexampleexplainshowtoconnectaspeakertothecameraandsetituptoplayawarningmessagewhenthecameradetects
motioninarestrictedarea.
Requiredhardware
•Activespeakerwithbuilt-inamplierandconnectingwires
NO NO
NO
TICE TICE
TICE
Makesurethecameraisdisconnectedfrompowerbeforemakingtheconnections.Reconnecttopowerafterconnectingthe
wires.
Physicalconnection
1.ConnecttheaudiowirefromthespeakertotheAUDIOOUTpinonthecamera.SeeProductoverviewonpage3.
2.ConnectthegroundingwirefromthespeakertotheGNDAUDIOOUTpinonthecamera.SeeProductoverviewonpage3.
Addaudiocliptothecamera
1.GotoSettings>Audio>Outputandclick
toaddyouraudioclip.
2.ClickAdd.
3.SelectUploadunderAddAudioClipOptions.
4.BrowsetolocatetheaudioclipandclickUpload.
Totriggerthecameratoplaytheaudioclipwhenitdetectsmotion,createanactionruleinthecamera’swebpage.
Directthecameraandopenthelocktoagatewhensomeoneisnearby
Thisexampleexplainshowtodirectthecameraandopenagatewhensomeonewantstoenterduringdaytime.Thisisdoneby
connectingaPIRdetectortotheproduct’sinputportandaswitchrelaytotheproduct’soutputport.
Requiredhardware
•MountedPIRdetector
•Switchrelayconnectedtothegatelock,inthiscasetheswitchisnormallyclosed(NC)
•Connectingwires
Physicalconnection
1.ConnectthewiresfromthePIRdetectortotheinputpin,seeI/Oconnectoronpage22.
2.Connectthewiresfromtheswitchtotheoutputpin,seeI/Oconnectoronpage22
CongureI/Oports
Youneedtoconnecttheswitchrelaytothecamerafromthecamera’swebpage.First,conguretheI/Oports:
SetthePIRdetectortoaninputport
1.GotoSystem>I/Oports.
