AXISM7011VideoEncoder
HardwareOverview
RS485/RS422Connector
TwoterminalblocksforRS485/RS422serialinterfaceusedtocontrolauxiliaryequipmentsuchasPTZdevices.
SDCardSlot
ForSDcardrecommendations,seewww.axis.com
ControlButton
Forlocationofthecontrolbutton,seeHardwareOverviewonpage7.
Thecontrolbuttonisusedfor:
•Resettingtheproducttofactorydefaultsettings.Seepage52.
•ConnectingtoanAXISVideoHostingSystemservice.Seepage45.Toconnect,pressandholdthebuttonforabout3
secondsuntiltheStatusLEDashesgreen.
•ConnectingtoAXISInternetDynamicDNSService.Seepage45.Toconnect,pressandholdthebuttonforabout3seconds.
LEDIndicators
Note
•TheStatusLEDcanbeconguredtoashwhileaneventisactive.
•TheStatusLEDcanbeconguredtoashforidentifyingtheunit.GotoSetup>SystemOptions>Maintenance.
StatusLED
Indication
GreenSteadygreenfornormaloperation.
Amber
Steadyduringstartupandwhenrestoringsettings.
RedFlashesredforrmwareupgradefailure.
NetworkLEDIndication
Green
Steadyforconnectiontoa100Mbit/snetwork.Flashesfornetworkactivity.
Amber
Steadyforconnectiontoa10Mbit/snetwork.Flashesfornetworkactivity.
UnlitNonetworkconnection.
PowerLEDIndication
Green
Normaloperation.
Amber
Flashesgreen/amberduringrmwareupgrade.
8

Axis M7011 Specifications

General

NTSC resolutions	720 x 480 pixels
Motion JPEG frame rate	30 fps
Maximum video resolution	720 x 576 pixels
Video compression formats	H.264, M-JPEG
PTZ control	Yes
Internal memory	256 MB
Angle of rotation	270 °
Compatible operating systems	Windows XP, Windows Vista, Windows Server 2008, Windows 7, Windows 8, Windows Server 2012
Bundled software	AXIS Camera Companion, AXIS Camera Station
Product color	Blue
Security algorithms	HTTPS, SSH, SSL/TLS
Password protection type	User
Wi-Fi	No
Supported network protocols	IPv4/v6, HTTP, HTTPS, SSL/TLS, QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP, SNMP v1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SFTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH
Copper ethernet cabling technology	100BASE-TX, 10BASE-T
BNC input ports	1
I/O terminal ports	0
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	71 g
Dimensions (WxDxH)	38 x 90 x 29 mm
