Axis M7116 User Manual

AXISM7116VideoEncoder
Specifications
Specifications
Productoverview
1
4xStatusLED
2
16xBNCconnectors
3
4xControlbutton
4
4xMicroSDcardslot
5
4xRS485/RS422connector
6
Powerconnector
7
EthernetRJ45
LEDindicators
StatusLED
Indication
Unlit
Connectionandnormaloperation.
GreenSteadygreenfornormaloperation.
Amber
Steadyduringstartup,duringresettofactorydefaultorwhenrestoringsettings.
NetworkLEDIndication
Green
Steadyforconnectiontoa1Gbit/snetwork.Flashesfornetworkactivity.
Amber
Steadyforconnectiontoa10/100Mbit/snetwork.Flashesfornetworkactivity.
UnlitNonetworkconnection.
SDcardslot
NO NO
NO
TICE TICE
TICE
•RiskofdamagetoSDcard.Donotusesharptools,metalobjects,orexcessiveforcewheninsertingorremovingthe
SDcard.Useyourngerstoinsertandremovethecard.
•Riskofdatalossandcorruptedrecordings.DonotremovetheSDcardwhiletheproductisrunning.UnmounttheSDcard
fromtheproduct’swebpagebeforeremoval.
ThisproductsupportsmicroSD/microSDHC/microSDXCcards.
20

Axis M7116 Specifications

General

Brand	Axis
Model	M7116
Category	Media Converter
Language	English
