AXIS P13 Series Installation Guide Page 11
ENGLISH
AXIS P1311: Adjust focus
To focus AXIS P1311 follow these instructions:
1. Open the product’s home page in a web browser.
2. Loosen the focus puller and turn the lens gently to focus the camera. Check the quality of the
image in the Live View window.
Note:
If the camera is mounted so that one cannot look at the image and turn the lens at the same
time, use the Focus Assistant instead. See below.
3. Retighten the focus puller.
Focus Assistant (AXIS P1311)
To focus AXIS P1311 using the Focus Assistant follow the instructions below:
1. Mount or place the camera so that it cannot be moved.
2. Power-on the camera and wait about 1 minute.
3. Set the camera to its extreme distant-focus position by loosening the focus puller and turning
the lens fully clockwise.
4. Press and quickly release the Control button. When the Status LED flashes green, the Focus
Assistant is enabled.
If the Status LED flashes either red or amber before you are able to adjust the lens, skip to step
7 to exit the Focus Assistant and repeat steps 3 - 7. See the notes below.
5. Gently turn the lens anti-clockwise until it stops. Do not force the lens too far or it will separate
from the camera.
Focus puller
Status LED
Control button
