AXIS P13 Series Installation Guide Page 5
ENGLISH
Install the hardware
Connect the cables
1. Connect the camera to the network using a shielded network cable.
2. Optionally connect external input/output devices, e.g. alarm devices. See page 18 for
information on the terminal connector pins.
3. Optionally connect an active speaker and/or external microphone.
4. Connect power, using one of the methods listed below:
• The supplied power connector.
• PoE (Power over Ethernet). If available, this is automatically detected when the network
cable is connected (see above).
5. Check that the indicator LEDs indicate the correct conditions. See the table on page 19 for
further details. Note that the Status LED can be configured to be unlit during normal operation.
Dimensions
!
IMPORTANT! - AXIS P1311/P1343/P1344 is designed for indoor and outdoor use. To
use the camera outdoors, it must be installed in an approved outdoor housing. Please
see www.axis.com for more information on outdoor housings.
Model H x W x D Weight
(power supply not included)
AXIS P1311 46 x 78 x 176 mm
(1.8” x 3.1” x 6.9”)
584 g
(1.29 lb)
AXIS P1343 46 x 78 x 190 mm
(1.8” x 3.1” x 7.5”)
585 g
(1.29 lb)
AXIS P1344 46 x 78 x 202 mm
(1.8” x 3.1” x 8.0”)
620 g
(1.37 lb)
