AXISP13-ESeries
RS485/RS422TX(B)
3
RS485/RS422TX(A)
4
TXpairforRS422and4-wireRS485
Important
Therecommendedmaximumcablelengthis30m(98.4ft).
CableArea
NO NO
NO
TICE TICE
TICE
•Usecablesthatkeepwithinthespeciedcablearea.
•Selectcablesincompliancewithyourlocalregulations.
•Makesureallcableholesareproperlysealed.
•Usecablegasketsorcableglandsthatmatchboththecableholeandthecablearea.
Diameter
AWG
From5to15mm(0.197to0.591in)
Approximatelyfrom4to6/0
Tocreateextracableholes,openthedrill-outslocatedinthebottomofthehousing.SeeHardware
Overviewonpage1 0.
Forinformationaboutaccessories,suchascablegasketsandcableglandsthatallowforother
cableareas,seewww.axis.com
18
