AXISP1365NetworkCamera
HardwareOverview
NetworkLEDIndication
Green
Steadyforconnectiontoa100Mbit/snetwork.Flashesfornetworkactivity.
Amber
Steadyforconnectiontoa10Mbit/snetwork.Flashesfornetworkactivity.
UnlitNonetworkconnection.
PowerLEDIndication
Green
Normaloperation.
Amber
Flashesgreen/amberduringrmwareupgrade.
StatusLEDBehaviorforFocusAssistant
Color
Indication
Green
FocusAssistantisenabled
Thelensisoptimallyadjusted
AmberThecamerahasbeenmoved,oranobjecthasbeenplacedinfrontofthelens.Exitandrestartthe
FocusAssistant.
Thelensislessoptimallyadjusted.
RedThecamerahasbeenmoved,oranobjecthasbeenplacedinfrontofthelens.Exitandrestartthe
FocusAssistant.
Thelensispoorlyadjusted.
ReplacetheLens
Note
Thereisnoneedtorestarttheproductafterchangingthelens.However,theproductmustberestartedifyouare
interchangingbetweenaP-Iris,DCirisorxed/manualirislens.Inordertosetthefocusandpositionthelens,theproduct
mustbeconnectedtothenetwork.
ItispossibletouseoptionallensesfortheAxisproduct.
Toreplacethelens:
1.Disconnecttheiriscable.
2.Unscrewthestandardlens.
3.Attachandscrewonthenewlens.
Note
IfyouselectaDCiriscongurationleforaP-Irislens,anerrormessagewillappearbelowtheiriscongurationtypeinthe
CameraSettingspage.ForcustomDCirislenses,selectGenericDCirisoption.
Tochangetheirisconguration:
1.GotoSetup>VideoandAudio>CameraSettings.Iriscongurationshowsthecurrentcongurediristype.
2.ClickEdit.
3.Selecttheinstalledirislensfromthedrop-downlistandclickOK.
TochangetheiriscongurationforP-Irislensesnotlistedinthedrop-downlist:
1.Downloadtheiriscongurationlefromwww.axis.com
9
