Axis P1448-LE Repainting Instructions

AXIS P14 Series
How to repaint the product
6
Preparation of the bottom base cover:
1) The top surface of the bottom base cover must be masked to ensure function of important features and
screws and gaskets, enable unit being reassembled.
Mask the entire top surface area:
2) The bottom of the bottom base cover must be masked to ensure function of important features and
screws and gaskets, enable unit being reassembled.
Please note: Cable side entry lid may be painted separately to fulfil your need of function.
Cable side entry lid

Axis P1448-LE Specifications

General

Type	IP security camera
PTZ modes	Digital PTZ
PTZ control	Yes
Certification	EN 55032 Class A, EN 50121-4, IEC 62236-4, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-003 Class A, VCCI Class A, RCM AS/NZS CISPR 32 Class A, KCC KN32 Class A, KN35, IEC/EN/UL 62368-1, IEC/EN/UL 60950-22, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, IEC/EN 60529 IP66/IP67, IEC/EN 62262 IK10, NEMA 250 Type 4X, IEC 62471
Languages support	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, KOR, POR, RUS
Number of languages	11
Placement supported	Indoor & outdoor
Connectivity technology	Wired
Wi-Fi	No
Streaming method	Multicast
Networking standards	IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
Ethernet interface type	Fast Ethernet
Supported network protocols	IPv4/v6, HTTP, HTTPS, SSL/TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP, SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, LLDP
Built-in HDD	-
Flash memory	512 MB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC, SD
Ethernet LAN (RJ-45) ports	1
Alert notification type	E-mail
IK code	IK10
Form factor	Bullet
Mounting type	Wall
Product color	Black, White
Housing material	Aluminum
International Protection (IP) code	IP67
Camera shutter speed	2 - 62500 s
Minimum illumination	0.04 lx
Behavior analysis	Line crossing detection
Sensor type	CMOS
Optical sensor size	1/2.5 \
Power source type	PoE
Power consumption (max)	12.95 W
Power consumption (typical)	7.1 W
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	-40 - 60 °C
Optical zoom	3.5 x
Focal length range	2.8 - 9.8 mm
Maximum aperture number	1.6
LED type	IR
Night vision distance	25 m
Total megapixels	8 MP
Maximum resolution	3840 x 2160 pixels
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness
Video compression formats	H.264, M-JPEG, MPEG4
Sample rate	48 kHz
Audio formats supported	ADPCM, G.711, G.726, LC-AAC, LPCM
Harmonized System (HS) code	85258900

Weight and Dimensions

Depth	260 mm
Weight	1000 g
Diameter	132 mm
