AXISP3707-PENetworkCamera
Aboutvideosettings
Aboutvideosettings
ItispossibletocongurethefollowingvideofeaturesinyourAxisproduct:
•Videostream.Seepage17.
•Streamproles.Seepage20.
•Camerasettings.Seepage20.
•Overlayimage.Seepage22.
•Privacymask.Seepage24.
Howtosetupvideostreams
Tosetuptheproduct’svideostreams,gotoVideo>VideoStream.
Thevideostreamsettingsaredividedintothefollowingtabs:
•Image.Seepage17.
•H.264.Seepage18.
•MJPEG.Seepage19.
Note
Videostreamcanbeconguredforeachchannel,includingquadstream.
Aboutthepixelcounter
Thepixelcountershowsthenumberofpixelsinanareaoftheimage.Thepixelcounterisusefulinsituationswherethereis
aspecicsizerequirement,forexampleinfacerecognition.
Thepixelcountercanbeused:
•Whensettingupavideostream,seeHowtosetupvideostreamsonpage17.UnderPreview,clickOpenandselectthe
Showpixelcounteroptiontoenabletherectangleintheimage.Usethemousetomoveandresizetherectangle,orenter
thenumberofpixelsintheWidthandHeighteldsandclickApply.
•WhenaccessingtheLiveViewpageinInternetExplorerwithAXISMediaControl(AMC)inWindows.Right-clickinthe
imageandselectPixelcounter.Usethemousetomoveandresizetherectangle.
ThedefaultimagesettingscanbeconguredunderVideo>VideoStream.SelecttheImagetab.
Thefollowingsettingsareavailable:
•Resolution.Selectthedefaultresolution.
•Compression.Thecompressionlevelaffectstheimagequality,bandwidthandlesizeofsavedimages;thelowerthe
compression,thehighertheimagequalitywithhigherbandwidthrequirementsandlargerlesizes.
•Rotateimage.Ifrequired,theimagecanberotated.
•Maximumframerate.Toavoidbandwidthproblems,theframerateallowedtoeachviewercanbeLimitedtoaxed
amount.Alternatively,theframeratecanbesetasUnlimited,whichmeanstheAxisproductalwaysdeliversthehighest
frameratepossibleunderthecurrentconditions.
•Overlaysettings.SeeAboutoverlaytextonpage22.
17
