AXIS
P5624–E
PTZ
Dome
Network
Camera
Video
Y
ou
can
add
a
new
mask,
re-size
the
mask
with
the
mouse,
choose
a
color
for
the
mask,
and
give
the
mask
a
name.
For
more
information,
see
the
online
help
.
Important
Adding
many
privacy
masks
may
affect
the
product’s
performance.
22
21
23
