Axis P5654-E Installation Guide

UnitedStatesofAmerica
Tel:+19786142000
Canada
Thisdigitalapparatuscomplieswith
CANICES-3(ClassA).Theproductshallbe
connectedusingashieldednetworkcable(STP)that
isproperlygrounded.Cetappareilnumériqueest
conformeàlanormeCANNMB-3(classeA).Leproduit
doitêtreconnectéàl'aided'uncâbleréseaublindé
(STP)quiestcorrectementmisàlaterre.
Europe
ThisdigitalequipmentfulllstherequirementsforRF
emissionaccordingtotheClassAlimitofEN55032.
Theproductshallbeconnectedusingashielded
networkcable(STP)thatisproperlygrounded.Notice!
ThisisaClassAproduct.Inadomesticenvironment
thisproductmaycauseRFinterference,inwhichcase
theusermayberequiredtotakeadequatemeasures.
Australia/NewZealand
Thisdigitalequipmentfulllstherequirements
forRFemissionaccordingtotheClassAlimitof
AS/NZSCISPR32.Theproductshallbeconnected
usingashieldednetworkcable(STP)thatisproperly
grounded.Notice!ThisisaClassAproduct.Ina
domesticenvironmentthisproductmaycauseRF
interference,inwhichcasetheusermayberequired
totakeadequatemeasures.
Japan
この装置は、クラスA機器です。この装置を
住宅環境で使⽤すると電波妨害を引き起こす
ことがあります。この場合には使⽤者が適切
な対策を講ずるよう要求されることがありま
す。VCCI‒A
本製品は、シールドネットワークケーブル
(STP)を使⽤して接続してください。また適切
に接地してください。
本製品は電気通信事業者（移動通信会社、固
定通信会社、インターネットプロバイダ等）
の通信回線（公衆無線LANを含む）に直接接
続することができません。本製品をインター
ネットに接続する場合は、必ずルータ等を経
由し接続してください。
Korea
이기기는업무용환경에서사용할목적으로적
합성평가를받은기기로서가정용환경에서사
용하는경우전파간섭의우려가있습니다.적절
히접지된STP(shieldedtwistedpair)케이블을
사용하여제품을연결하십시오.
Safety
ThisproductcomplieswithIEC/EN/UL62368-1,
safetyofaudio/videoandITequipment,and
IEC/EN/UL60950-22,SafetyofInformation
TechnologyEquipment.
Theproductshallbegroundedeitherthrougha
shieldednetworkcable(STP)orotherappropriate
method.
Thepowersupplyusedwiththisproductshallfulll
oneofthefollowingrequirements:
•SafetyExtraLowVoltage(SELV)accordingto
clause2.2ofIEC/EN/UL60950-1andLimited
PowerSource(LPS)accordingtoclause2.5of
IEC/EN/UL60950-1orCEC/NECClass2source
ofsupplyasdenedintheCanadianElectrical
Code,CSAC22.1andNationalElectricalCode,
ANSI/NFPA70
•Class1electricalenergysource(ES1)and
Class2powersource(PS2)ratedoutput
powerlimitedto≤100Waccordingto
IEC/EN/UL62368-1
WhenusedwithPoweroverEthernet(PoE),the
PowerSourcingEquipment(PSE)shallcomplywith
IEEE802.3af/802.3atandLimitedPowerSource(LPS)
accordingtoclause2.5ofIEC/EN/UL60950-1or
annexQofIEC/EN/UL62368-1.
WerecommendtheuseofAxisPoE+midspansorAxis
PoE+switches.
Disposalandrecycling
Whenthisproducthasreachedtheendofits
usefullife,disposeofitaccordingtolocallawsand
regulations.Forinformationaboutyournearest
designatedcollectionpoint,contactyourlocal
authorityresponsibleforwastedisposal.Inaccordance
withlocallegislation,penaltiesmaybeapplicablefor
incorrectdisposalofthiswaste.
Europe
Thissymbolmeansthattheproductshallnotbe
disposedoftogetherwithhouseholdorcommercial
waste.Directive2012/19/EUonwasteelectrical
andelectronicequipment(WEEE)isapplicablein
theEuropeanUnionmemberstates.Toprevent
potentialharmtohumanhealthandtheenvironment,
theproductmustbedisposedofinanapproved
andenvironmentallysaferecyclingprocess.For
informationaboutyournearestdesignatedcollection
point,contactyourlocalauthorityresponsiblefor
wastedisposal.Businessesshouldcontacttheproduct
supplierforinformationabouthowtodisposeofthis
productcorrectly.
Thisproductcomplieswiththerequirementsof
Directive2011/65/EUand2015/863ontherestriction
oftheuseofcertainhazardoussubstancesinelectrical
andelectronicequipment(RoHS).
China
Thisproductcomplieswiththerequirements
ofSJ/T11364-2014,Markingfortherestrictionof
hazardoussubstancesinelectricalandelectronic
products.
有毒有害物质或元素
部
件
名
称
铅
(Pb)
汞
(Hg)
镉
(Cd)
六
价
铬
(Cr-
(VI))
多
溴
联
苯
(PB-
B)
多
溴
二
苯
醚
(PB-
DE)

Axis P5654-E Specifications

General

Type	IP security camera
Certification	50121-4, EN 55024, EN 55032 Class A, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC 15 B A, ICES-3(A)/NMB-3(A), IEC 62236-4, KC KN32 A, KC KN35, RCM AS/NZS CISPR 32 A, VCCI A IEC/EN/UL 62368-1, IEC/EN/UL 60950-22 IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, EC 60068-2-78, IEC/EN 60529 IP66, IEC/EN 62262 IK10, NEMA 250 4X NIST SP500-267, IPv6 USGv6
Placement supported	Outdoor
Connectivity technology	Wired
Infrared (IR) cut-off filter	Yes
Bit rate control	Constant Bit Rate (CBR), Variable Bit Rate (VBR)
Total megapixels	- MP
Maximum resolution	1280 x 720 pixels
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness
Video compression formats	AVC, H.264, H.265, HEVC, M-JPEG
Supported graphics resolutions	320 x 180, 1280 x 720 (HD 720)
Sensor type	CMOS
Number of sensors	1
Optical sensor size	1/2.8 \
Digital zoom	12 x
Optical zoom	21 x
Focal length range	4 - 8.6 mm
Maximum aperture number	4.5
Minimum aperture number	1.6
Pan range	0 - 360 °
Pan speed	350 °/sec
Tilt angle range	0 - 180 °
Camera shutter speed	1/66500 - 2 s
Minimum illumination	0.01 lx
Wi-Fi	No
Networking standards	IEEE 802.1x, IEEE 802.3at
Ethernet interface type	Fast Ethernet
Supported network protocols	IPv4, IPv6 USGv6, HTTP, HTTPS, SSL/TLS, QoS L3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP , SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, NTCIP, LLDP, CDP
IK code	IK10
Form factor	Dome
Mounting type	Ceiling/wall
Product color	White
Housing material	Aluminum
International Protection (IP) code	IP66
Flash memory	512 MB
Internal memory	1024 MB
Compatible memory cards	SD, SDHC, SDXC
AC input voltage	100 - 240 V
Power source type	AC, PoE
Power consumption (max)	37 W
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	-30 - 50 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 100 %
Harmonized System (HS) code	85258900

Weight and Dimensions

Height	217 mm
Weight	2500 g
Diameter	188 mm
