AXISQ1615MkIINetworkCamera
ProductTemperatureHumidity
AXISQ1615MkII0°Cto55°C
(32°Fto122°F)
10-85%RH(non-condensing)
Connectors
I/Oconnector
4–pinterminalblock
Foranexamplediagram,seeConnectionDiagramsonpage15.
FunctionPinNotes
Specications
0VDC(-)
1
DCoutput
2
Canbeusedtopowerauxiliaryequipment.
Note:Thispincanonlybeusedaspowerout.
12VDC
Maxload=50mA
Digitalinput–Connecttopin1toactivate,
orleaveoating(unconnected)todeactivate.
0tomax30VDC Congurable
(Inputor
Output)
3–
4
Digitaloutput–Connectedtopin1when
activated,oating(unconnected)when
deactivated.Ifusedwithaninductiveload,
e.g.arelay,adiodemustbeconnectedin
parallelwiththeload,forprotectionagainst
voltagetransients.
0tomax30VDC,open
drain,100mA
16
