Axis q1615 MK II - Power Connector Specifications; Audio Connector Specifications

AXISQ1615MkIINetworkCamera
PowerConnector
2-pinterminalblockforDCpowerinput.UseaSafetyExtraLowVoltage
(SELV)compliantlimitedpowersource(LPS)witheitheraratedoutput
powerlimitedto≤100Woraratedoutputcurrentlimitedto≤5A.
AudioConnector
3.5mmaudio
connectors(stereo)
1Tip2Ring
3Sleeve
AudioInputBalanced:‘Hot’signal
Microphone/Linein
Unbalanced:Microphone/Line
in
Balanced:‘Cold’signal
Microphone/Linein
Unbalanced:Unused
Ground
AudioOutput
Lineout,mono(stereo
connectorcompatible)
Lineout,mono(stereo
connectorcompatible)
Ground
Theinternalmicrophoneisusedbydefault;theexternalmicrophoneisusedwhenconnected.Itis
possibletodisabletheinternalmicrophonebyconnectingaplugtothemicinput.
RS485/422Connector
Two2-pinterminalblocksforRS485/RS422serial
interface.Theserialportcanbeconguredtosupport:
•Two-wireRS485halfduplex
•Four-wireRS485fullduplex
•Two-wireRS422simplex
•Four-wireRS422fullduplexpointtopoint
communication
