AXISQ1615MkIINetworkCamera
•Levellingassistant–Thisfunctionhelpstoensurethecameraislevel.Pressthebutton
forabout3secondstostartthelevellingassistantandpressagaintostoptheleveling
assistant.ThestatusLEDandbuzzersignalassistlevellingofthecamera,seeStatusLED
BehaviorandBuzzerSignalforLevellingAssistantonpage12.Thecameraislevelwhen
thebuzzerbeepscontinuously.
•Focusassistant–ThisfunctionisusedforenablingtheFocusAssistant.Toenable
thefocusassistant,pressandveryquicklyreleasethebutton.Pressagaintostopthe
focusassistant.
ConnectionDiagrams
I/OConnector
1
0VDC(-)
2
DCoutput12V,max50mA
A
I/Oconguredasinput
B
I/Oconguredasoutput
Specications
OperatingConditions
TheAxisproductisintendedforindooruse.
15
