AXISQ1656-LEBoxCamera

Thewebinterface

Stabilizermargin:Usetheslidertoadjustthesizeofthestabilizermargin,whichdeterminesthelevelofvibrationto

stabilize.Iftheproductismountedinanenvironmentwithalotofvibration,movetheslidertowardsMax.Asaresult,asmaller

sceneiscaptured.Iftheenvironmenthaslessvibration,movetheslidertowardsMin.

Straightenimage

:Turnonandusetheslidertostraightentheimagehorizontallybyrotatingandcroppingitdigitally.The

functionalityisusefulwhenit’snotpossibletomountthecameraexactlylevel.Ideally,straightentheimageduringinstallation.

:Clicktoshowasupportinggridintheimage.

:Clicktohidethegrid.

Theimagebeforeandafterithasbeenstraightened.

Trafccamerainstallationassistance

Capturesettings

•Cameraheight:Enterthedistancebetweenthecameraandtheground.

•Roaddistance:Enterthedistancebetweenthecameraandthemiddleoftheroad.

•Typicalcarspeed:Enterthetypicalcarspeed.

•Accelerometer:Turnontoautomaticallygetthedistancebetweenthecameraandthecarsontheroad.

•Cardistance:Enterthedistancebetweenthecameraandthecarsontheroad.

Installationoverview:Installationoverviewprovidesthepositionandangleyoushouldinstallyourcameraforoptimalview.It

alsoindicatesifthereisneedforanychangeinhowyoumountthecamera.

•Verticalangle:Thisshouldbebetween0and29foragoodtiltposition.

•Horizontalangle:Thisshouldbebetween0and29foragoodpanposition.

•Rollangle:Thisshouldbebetween0and24degreesforagoodrotation.

•Cardistance:Thisisthedistancethatshouldbebetweenthemovingvehiclesandthecamera.

Imagesettings:AnoverviewoftheMaxshutterandSceneproleyou’veconguredwiththesesettings.

•Applysettings:Clicktoactivatetheconguration.Yourdevicereloadsandupdatesthesceneprole.


Appearance
