AXISQ1656-LEBoxCamera
Specifications
Specifications
Productoverview
12
11
4321 5 6 7 8 9 10
1
Weathershield
2
Wiper
3
Window
4
Lightsensor
5
IRilluminationLED
6
Opticalunit
7
Springloadedthumbscrew(4x)
8
Cablecover
9
Intrusionalarmsensor
10
IK10tool
11
Safetywire
12
Intrusionalarmmagnet
NO NO
NO
TICE TICE
TICE
Donotlifttheproductinthecablecover.
61
