Axis Q1656 Series User Manual

AXISQ1656BoxCameraSeries
Thewebinterface
Installation
Capturemode:Acapturemodeisapresetcongurationthatdeneshowthecameracapturesimages.Whenyouchange
thecapturemode,itcanaffectmanyothersettings,suchasviewareasandprivacymasks.
Mountingposition
:Theorientationoftheimagecanchangedependingonhowyoumountthecamera.
Powerlinefrequency:Tominimizeimageicker,selectthefrequencyyourregionuses.TheAmericanregionsusuallyuse60Hz.
Therestoftheworldmostlyuses50Hz.Ifyou'renotsureofyourregion'spowerlinefrequency,checkwiththelocalauthorities.
Rotate:Selectthepreferredimageorientation.
P-Irislens:Selecttheinstalledandsupportedlens.Restartthecameraforthechangestotakeeffect.
Zoom:Usetheslidertoadjustthezoomlevel.
Focus:Usetheslidertomanuallysetthefocus.
AF:Clicktomakethecamerafocusontheselectedarea.Ifyoudon’tselectanautofocusarea,thecamerafocusesonthe
entirescene.
Autofocusarea:Click
toshowtheautofocusarea.Thisareashouldincludetheareaofinterest.
Resetfocus:Clicktomakethefocusreturntoitsoriginalposition.
Note
Incoldenvironments,itcantakeseveralminutesforthezoomandfocustobecomeavailable.
Imagecorrection
Important
Werecommendyounottousemultipleimagecorrectionfeaturesatthesametime,sinceitcanleadtoperformanceissues.
Barreldistortioncorrection(BDC)
:Turnontogetastraighterimageifitsuffersfrombarreldistortion.Barreldistortion
isalenseffectthatmakestheimageappearcurvedandbentoutwards.Theconditionisseenmoreclearlywhentheimageis
zoomedout.
Crop
:Usetheslidertoadjustthecorrectionlevel.Alowerlevelmeansthattheimagewidthiskeptattheexpenseof
imageheightandresolution.Ahigherlevelmeansthatimageheightandresolutionarekeptattheexpenseofimagewidth.
Removedistortion:Usetheslidertoadjustthecorrectionlevel.Puckermeansthattheimagewidthiskeptattheexpense
ofimageheightandresolution.Bloatmeansthatimageheightandresolutionarekeptattheexpenseofimagewidth.
Imagestabilization:Turnontogetasmootherandsteadierimagewithlessblur.Werecommendthatyouuseimage
stabilizationinenvironmentswherethedeviceismountedinanexposedlocationandsubjecttovibrationsdueto,forexample,
windorpassingtrafc.
Focallength
:Usetheslidertoadjustthefocallength.Ahighervalueleadstohighermagnicationandanarrowerangle
ofview,whilealowervalueleadstoalowermagnicationandawiderangleofview.
21

Axis Q1656 Series Specifications

General

Video Compression	Motion JPEG
Network	Ethernet 10BASE-T/100BASE-TX, RJ45
Ingress Protection	IP66, NEMA 4X
Minimum Illumination	B/W: 0.01 lux
Resolutions	1920x1080 to 320x180
Audio Compression	AAC-LC, G.711, G.726
Security	Password protection, IP address filtering, HTTPS encryption, IEEE 802.1X
Field of View	Horizontal: 102° - 33°, Vertical: 56° - 19°
Day and Night	Automatically removable infrared-cut filter for day/night functionality
