AXISQ1656BoxCameraSeries
PTZdrivers
AutoIris
yes
AutoFocus
yes
IrCutFilter
no
BackLight
yes
OSDMenu
yes
Connection
FortheRS485/RS422pinassignmentonyourdevice,seeRS485/RS422connectoronpage63.
Tochangeserialportsettings,gotoSystem>Plaincong>Serialinthedevice’swebinterface.
Visca
Thisisalistofmodelssupportedbythisdriver.ThephysicalinstallationdependsonyourAxisproductandthePTZunit.
Important
CheckwhatserialcommunicationyourAxisproductandthePTZunitwillsupport.
SupportedmodelswithRS4224-wireinterface:
•SonyEVI-D70/D70P
•WISKADCP-27(PT-head)
SupportedmodelswithRS232interface(mayrequireexternalRS422-4-wire/RS232converter):
•AxisEVI-D30/D31
•SonyEVI-G20/G21
•SonyEVI-D30/D31
•SonyEVI-D100/D100P
•SonyEVI-D70/D70P
OthermodelsmaybesupportedbutthishasnotbeenveriedbyAxis.
Technicalinformation
DEFAULTcapabilitiesforPTZdriver:
Driver
Visca/EVI
Version
4.11
DEFAULTserialconguration:
PortMode
RS422
BaudRate
9600
DataBits
8
StopBits
1
ParityNone
DEFAULTsupportedcapabilitiesinthisPTZdriver:
67

Axis Q1656 Series Specifications

General

Video Compression	Motion JPEG
Network	Ethernet 10BASE-T/100BASE-TX, RJ45
Ingress Protection	IP66, NEMA 4X
Minimum Illumination	B/W: 0.01 lux
Resolutions	1920x1080 to 320x180
Audio Compression	AAC-LC, G.711, G.726
Security	Password protection, IP address filtering, HTTPS encryption, IEEE 802.1X
Field of View	Horizontal: 102° - 33°, Vertical: 56° - 19°
Day and Night	Automatically removable infrared-cut filter for day/night functionality
