Axis Q1656 Series User Manual

AXISQ1656BoxCameraSeries
PTZdrivers
PTZdrivers
APTP
Thisisalistofmodelssupportedbythisdriver.ThephysicalinstallationdependsonyourAxisproductandthePTZunit.
Important
CheckwhatserialcommunicationyourAxisproductandthePTZunitwillsupport.
SupportedmodelswithRS4852-wireinterface:
•AXIST99APositioningUnitSeries.
ForinformationaboutcompatibleAxisproducts,seeaxis.com.
OthermodelsmaybesupportedbutthishasnotbeenveriedbyAxis.
Technicalinformation
DEFAULTcapabilitiesforPTZdriver:
DriverAPTP
Version
1.1.0
DEFAULTserialconguration:
PortMode
RS485
BaudRate
115200
DataBits
8
StopBits
1
ParityNone
DEFAULTsupportedcapabilitiesinthisPTZdriver:
Note
DifferentPTZunitsmayhaveothercapabilities(bothlessandmore).
MovementAbsoluteRelative
Continuous
Pan
yesyesyes
Tilt
yesyesyes
Connection
FortheRS485/RS422pinassignmentonyourdevice,seeRS485/RS422connectoronpage63.
Tochangeserialportsettings,gotoSystem>Plaincong>Serialinthedevice’swebinterface.
Pelco
Thisisalistofmodelssupportedbythisdriver.ThephysicalinstallationdependsonyourAxisproductandthePTZunit.
Important
CheckwhatserialcommunicationyourAxisproductandthePTZunitwillsupport.
65

Axis Q1656 Series Specifications

General

Video Compression	Motion JPEG
Network	Ethernet 10BASE-T/100BASE-TX, RJ45
Ingress Protection	IP66, NEMA 4X
Minimum Illumination	B/W: 0.01 lux
Resolutions	1920x1080 to 320x180
Audio Compression	AAC-LC, G.711, G.726
Security	Password protection, IP address filtering, HTTPS encryption, IEEE 802.1X
Field of View	Horizontal: 102° - 33°, Vertical: 56° - 19°
Day and Night	Automatically removable infrared-cut filter for day/night functionality
