Axis Q1656 Series User Manual

AXISQ1656BoxCameraSeries
Specifications
Buzzer
Buzzersignalforlevelingassistant
Forinformationaboutthecontrolbuttonusedforlevelingtheimage,seepage61.
Buzzer
Cameraposition
Continuousbeep
Level
FastbeepAlmostlevel
MediumbeepsNotlevel
Slowbeeps
Farfromlevel
SDcardslot
NO NO
NO
TICE TICE
TICE
•RiskofdamagetoSDcard.Don’tusesharptools,metalobjects,orexcessiveforcewheninsertingorremovingtheSDcard.
Useyourngerstoinsertandremovethecard.
•Riskofdatalossandcorruptedrecordings.UnmounttheSDcardfromthedevice’swebinterfacebeforeremovingit.
Don’tremovetheSDcardwhiletheproductisrunning.
ThisdevicesupportsmicroSD/microSDHC/microSDXCcards.
ForSDcardrecommendations,seeaxis.com.
microSD,microSDHC,andmicroSDXCLogosaretrademarksofSD-3CLLC.microSD,microSDHC,microSDXCare
trademarksorregisteredtrademarksofSD-3C,LLCintheUnitedStates,othercountriesorboth.
Buttons
Controlbutton
Thecontrolbuttonisusedfor:
•Resettingtheproducttofactorydefaultsettings.SeeResettofactorydefaultsettingsonpage69.
•Ensuringthecameraislevel.Pressthebuttonfornotmorethantwosecondstostartthelevelingassistantandpress
againtostop.Thebuzzersignal(seepage61)assistlevelingofthecamera.Thecameraislevelwhenthebuzzerbeeps
continuously.
Connectors
Networkconnector
RJ45EthernetconnectorwithPoweroverEthernet(PoE).
Audioconnector
•Audioin–3.5mminputforadigitalmicrophone,ananalogmonomicrophone,oraline-inmonosignal(leftchannelis
usedfromastereosignal).
•Audioout–3.5mmoutputforaudio(linelevel)thatcanbeconnectedtoapublicaddress(PA)systemoranactive
speakerwithabuilt-inamplier.Astereoconnectormustbeusedforaudioout.
61

Axis Q1656 Series Specifications

General

Video Compression	Motion JPEG
Network	Ethernet 10BASE-T/100BASE-TX, RJ45
Ingress Protection	IP66, NEMA 4X
Minimum Illumination	B/W: 0.01 lux
Resolutions	1920x1080 to 320x180
Audio Compression	AAC-LC, G.711, G.726
Security	Password protection, IP address filtering, HTTPS encryption, IEEE 802.1X
Field of View	Horizontal: 102° - 33°, Vertical: 56° - 19°
Day and Night	Automatically removable infrared-cut filter for day/night functionality
