Axis Q1715 User Manual

AXISQ1715BlockCamera
Thewebinterface
Shockdetector:Turnontogenerateanalarmifthedeviceishitbyanobjectorifitistamperedwith.
Sensitivitylevel:Movetheslidertoadjustthesensitivitylevelatwhichthedeviceshouldgenerateanalarm.Alowvalue
meansthatthedeviceonlygeneratesanalarmifthehitispowerful.Ahighvaluemeansthatthedevicegeneratesanalarm
evenwithmildtampering.
Accessories
PTZ
UsePTZdriverswhenyouconnecttoexternalPTZdevices.
•Driver:SelectthedriverforyourPTZdevice.Thedriverisrequiredfortheconnecteddevicetofunctioncorrectly.
•Devicetype:Selectthetypeofdeviceyou’reconnectingtofromthedrop-downlist.Thedevicetypeisdriver
dependent.
•Deviceid:Typetheid,oraddress,oftheconnectedPTZdevice.Youcanndtheaddressinthedocumentationof
thedevice.
FormoreinformationaboutPTZdrivers,seePTZdriversonpage71.
I/Oports
Usedigitalinputtoconnectexternaldevicesthatcantogglebetweenanopenandclosedcircuit,forexample,PIRsensors,door
orwindowcontacts,andglassbreakdetectors.
UsedigitaloutputtoconnectexternaldevicessuchasrelaysandLEDs.YoucanactivateconnecteddevicesthroughtheVAPIX®
ApplicationProgrammingInterfaceorthewebinterface.
Port
Name:Editthetexttorenametheport.
Direction:indicatesthattheportisaninputport.indicatesthatit’sanoutputport.Iftheportiscongurable,
youcanclicktheiconstochangebetweeninputandoutput.
Normalstate:Click
foropencircuit,andforclosedcircuit.
Currentstate:Showsthecurrentstateoftheport.Theinputoroutputisactivatedwhenthecurrentstateisdifferentfromthe
normalstate.Aninputonthedevicehasanopencircuitwhenit’sdisconnectedorwhenthereisavoltageabove1VDC.
Note
Duringrestart,theoutputcircuitisopen.Whentherestartiscomplete,thecircuitgoesbacktothenormalposition.Ifyou
changeanysettingsonthispage,theoutputcircuitsgobacktotheirnormalpositionsregardlessofanyactivetriggers.
Supervised
:Turnontomakeitpossibletodetectandtriggeractionsifsomeonetamperswiththeconnectiontodigital
I/Odevices.Inadditiontodetectingifaninputisopenorclosed,youcanalsodetectifsomeonehastamperedwithit(thatis,cut
orshorted).Tosupervisetheconnectionrequiresadditionalhardware(end-of-lineresistors)intheexternalI/Oloop.
Edge-to-edge
Pairing
PairingallowsyoutouseacompatibleAxisnetworkspeakerormicrophoneasifit’spartofthecamera.Oncepaired,thenetwork
speakeractsasanaudiooutdevicewhereyoucanplayaudioclipsandtransmitsoundthroughthecamera.Thenetworkmicrophone
willtakeupsoundsfromthesurroundingareaandmakeitavailableasanaudioinputdevice,usableinmediastreamsandrecordings.
