Axis Q1715 - Page 70

AXISQ1715BlockCamera
Specifications
5
CongurableI/O
6
CongurableI/O
Powerconnector
2-pinterminalblockforDCpowerinput.UseaSafetyExtraLowVoltage(SELV)compliantlimitedpowersource(LPS)witheither
aratedoutputpowerlimitedto≤100Woraratedoutputcurrentlimitedto≤5A.
RS485/RS422connector
Two2-pinterminalblocksforRS485/RS422serialinterfaceusedtocontrolauxiliaryequipmentsuchaspan-tiltdevices.
Theserialportcanbeconguredtosupport:
•Two-wireRS485halfduplex
•Four-wireRS485fullduplex
•Two-wireRS422simplex
•Four-wireRS422fullduplexpointtopointcommunication
FunctionPinNotes
RS485/RS422TX(B)
1
RS485/RS422TX(A)
2
TXpairforRS422and4-wireRS485
RS485BaltRS485/422RX(B)
3
RS485AaltRS485/422RX(A)
4
RXpairforallmodes(combinedRX/TXfor2-wireRS485)
Important
Themaximumcablelengthis30m(98ft).
