Page 8 AXIS Q6032/Q6034/Q6035 Installation Guide
Install the hardware
The network camera can be mounted with the cables routed through or along the wall or ceiling.
Prepare for installation
Read all the instructions before preparing to install the network camera since several installation
preparation steps require removing the dome ring and the dome cover and would benefit from
being completed together.
• The network camera is supplied with a clear transparent cover and a smoked transparent
cover. If required, follow the instructions
Replace the clear/smoked dome cover (optional) ,
below to replace the dome cover.
• A standard or high capacity SD card (not included) is required to store images locally in the
network camera. Follow the instructions
Install an SD card (optional) , below to remove the
dome cover and install an SD card.
Replace the clear/smoked dome cover (optional)
1. Loosen the 4 dome ring screws and remove the dome ring and the dome cover, see illustration
on page 6.
2. Remove the 4 dome bracket screws and remove the dome bracket and the dome cover from the
dome ring.
3. Attach the dome bracket and the dome cover to the dome ring and tighten the 4 screws.
4. If installing an SD card, refer to the instructions
Install an SD card (optional) , below.
5. Put the dome ring with the dome cover back in the original position and tighten the screws.
Note:
Be careful not to scratch or damage the dome cover. If possible, keep the protective plastic
on the dome cover until the installation is complete.
Install an SD card (optional)
1. Loosen the 4 dome ring screws and remove the dome ring and the dome cover, see illustration
on page 6.
2. Insert an SD card (not included) into the SDHC (Secure Digital High Capacity) card slot.
3. Put the dome ring with the dome cover back in the original position and tighten the screws.
Notes:
The SD card is automatically mounted when inserted into the SDHC card slot. However,
before removing the SD card it should be unmounted through the camera’s web pages. Go
to Setup > System Options > Storage > SD Card and click Unmount. For more informa-
tion, please see the User Manual available from the AXIS Network Video Product CD sup-
plied with this product or from the website at www.axis.com
!
IMPORTANT! - To use the network camera outdoors, it must be installed in an approved
outdoor housing. Please see www.axis.com for more information on outdoor products.

Axis Q6035 Specifications

General

Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p, 720p
Video formats supported	H.264, M-JPEG, MPEG4
Supported graphics resolutions	1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Pan range	0 - 360 °
Tilt angle range	0 - 180 °
Camera shutter speed	1/30000 - 1/4 s
Minimum illumination	0.04 lx
Sensor type	CMOS
Optical sensor size	1/2.8 \
Digital zoom	12 x
Optical zoom	20 x
Focus adjustment	1.6 - 3.5
Focal length range	4.7 - 94 mm
Security algorithms	802.1x RADIUS
Video motion detection	Yes
Certification	EN 55022 B, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, EN 55024, FCC 15 B B, ICES-003 B, VCCI B, C AS/NZS CISPR 22, IEC 60529 IP52, IEC 60721-4-3 Class 3K3, 3M3 GS, UL, cUL, CE, FCC, VCCI, CB, KCC, UL-AR
Processor model	ARTPEC-3
Placement supported	Indoor
Connectivity technology	Wired
Built-in HDD	No
Flash memory	128 MB
Internal memory	256 MB
Compatible memory cards	SD, SDHC
Form factor	Dome
Product color	White
Housing material	Metal
International Protection (IP) code	IP52
Headphone outputs	1
Audio formats supported	AAC, MS-ADPCM, PCM
Cabling technology	10/100Base-T(X)
Supported network protocols	IPv4/v6, HTTP, HTTPS*, QoS 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Compliance industry standards	802.3at
AC input voltage	100-240 V
Power source type	PoE
AC input frequency	50 Hz
Power consumption (typical)	30 W
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Width	198 mm
Height	240 mm
Weight	2600 g
