Axis Q6045-C Mk II User Manual

AXISQ6045-CMkIIPTZDomeNetworkCamera
Multi-ConnectorCable
Multi-ConnectorCable
Note
Thesuppliedmulti-connectorcableisrequiredinordertomaintainthecamera’sNEMA/IPrating.
Themulti-connectorcableisconnectedtothecamera’smulti-connector,seeHardwareOverviewonpage6.
Thewiresareconnectedtothesuppliedmediaconverterswitch,seeMediaConverterSwitchonpage8.
Thecableprovidesthefollowingsignals:
•DCpowertocamera
•Network(Ethernet10/100Base-T)
•Input/Output(I/O)
1
2
3
4
5
6
7
8
9
10
12 11
1 8
2 7
9
3 6
4 5
Multi-connectorcableoverview
1
Powerwire(red)
2
DigitalI/Owire(blue)
3
Ethernetwire(green/white)
4
Ethernetwire(green)
5
Ethernetwire(orange/white)
6
Ethernetwire(orange)
7
DigitalI/Owire(yellow)
8
Groundwire(black)
9
Powerwire(red)
10
Ethernetwirefoilshield(2x)
11
Outerfoilshield
12
Braidedshieldcoil
FunctionPin–wireNotes
Specications
Digitalinput–Connecttopin8toactivate,or
leaveoating(unconnected)todeactivate.
0tomax30VDC
Congurable(Input
orOutput)
2–blue
7–yellow
Digitaloutput–Connectedtopin1when
activated,oating(unconnected)when
deactivated.Ifusedwithaninductiveload,e.g.a
relay,adiodemustbeconnectedinparallelwith
theload,forprotectionagainstvoltagetransients.
0tomax30VDC,open
drain,100mA
59
