AXISQ6045-CMkIIPTZDomeNetworkCamera
HardwareOverview
MediaConverterSwitch
1
2
3
4
5
6
7
8
10
9
11
12
13
1
Powerconnector(DCinput)
2
Powerconnector(DCoutput)
3
Networkconnector(internal)
4
NetworkslotSFP(external)(2x)
5
NetworkconnectorRJ45(external)(2x)
6
CameraLEDindicator
7
NetworkLEDindicator(4x)
8
PowerLEDindicator
9
Groundclip
10
I/Oconnector(internal)
11
I/Oconnector(external)
12
Multi-connectorcable
13
Groundscrew
MediaConverterSwitchConnectors
Fortechnicalspecications,seepage65.
NO NO
NO
TICE TICE
TICE
Theproductshallbeconnectedusingashieldednetworkcable(STP)oranopticalbercable.Allcablesconnectingthe
producttothenetworkshallbeintendedfortheirspecicuse.Makesurethatthenetworkdevicesareinstalledin
accordancewiththemanufacturer’sinstructions.Forinformationaboutregulatoryrequirements,seeElectromagnetic
Compatibility(EMC)onpage2.
Important
Themediaconverterswitchdoesnotsupporthotswapping.Disconnectpowerfromtheswitchbeforeswappingcameras.An
attempttohotswapcouldcausetheswitchtofreeze,inwhichcaseitmustberestarted.
Powerconnector(DCinput)-2-pinterminalblockforpowerinput.
Powerconnector(DCoutput)-Two2-pinterminalblockforpoweroutput(pin4isnotused).
NetworkconnectorRJ45(external)-TwoRJ45connectors(10/100Base-T)fornetworkconnectivity.
8
