AXISQ6045-CMkIIPTZDomeNetworkCamera
TechnicalSpecifications
Networkconnector
Two2-pinEthernetterminalblocks.
I/Oterminalconnector
2-pinterminalblock.
ExternalConnectors
GroundScrewGroundscrewforconnectingthemediaconverter
switchtoearthground.Makesurethatbothendsof
thegroundingwireareincontactwiththeirrespective
groundingsurfaces.
Powerconnector
2-pinterminalblockforpowerinput.
- +
21
FunctionPinNotes
Specications
0VDC(-)
1
0VDC DCinput
12VDC
2
Powerinfrompowersupply(sold
separately)
12.0-13.2VDC,min75W
I/Oterminalconnector
6-pinterminalblocksfor:
•DigitalInput/Output
•Power(DCoutput)
•0VDC(-)
21 43 65
FunctionPinNotes
Specications
0VDC(-)
1,4,6
0VDC
DCoutput
2
Powerout
12VDC,50mA
Digitalinput
0tomax30VDC
CongurableI/O1(Inputor
Output)
3
Digitaloutput(transistor–open
collector)
0tomax30VDC,opendrain,
100mA
Digitalinput
0tomax30VDC
CongurableI/O2(Inputor
Output)
5
Digitaloutput(transistor–open
collector)
0tomax30VDC,opendrain,
100mA
68
