Axis Q6045-E Mk II User Manual

AXISQ6045-EMkIIPTZDomeNetworkCamera
Video
CameraSettings
TheVideo>CameraSettingspageprovidesaccesstoadvancedimagesettingsfortheAxisproduct.
ImageAppearance
IncreasingtheColorlevelincreasesthecolorsaturation.Thevalue100givesmaximumcolorsaturation.Thevalue0givesa
blackandwhiteimage.
TheimageBrightnesscanbeadjustedintherange0–100,whereahighervalueproducesabrighterimage.
IncreasingtheSharpnesscanincreasebandwidthusage.Asharperimagemightincreaseimagenoiseespeciallyinlowlight
conditions.Alowersettingreducesimagenoise,butthewholeimagewillappearlesssharp.
WhiteBalance
Whitebalanceisusedtomakecolorsintheimageappearthesameregardlessofthecolortemperatureofthelightsource.TheAxis
productcanbesettoautomaticallyidentifythelightsourceandcompensateforitscolor.Alternatively,selectthetypeoflight
sourcefromthedrop-downlist.Foradescriptionofeachavailablesetting,seetheonlinehelp
.
WideDynamicRange
WideDynamicRange(WDR)processingbalancesthebrightestanddarkestsectionsofascenetoproduceanimagethatisbalanced
inlightingtoprovidemoredetail.Widedynamicrangecanimprovetheexposurewhenthereisaconsiderablecontrastbetweenlight
anddarkareasintheimage.TherearethreedifferentWDRmodes:
WDR1-contrast
WDR2-doubleexposure
WDR3-contrastanddoubleexposure
ThedifferentWDRsettingsadjustforvariousamountsofcontrastintheimage.UseahigherWDRnumberforahighercontrast.
EnableWDRinintensebacklightconditions.DisableWDRinlowlightconditionsforoptimalexposure.
ExposureSettings
Exposurecontrol-Thesesettingsisusedtoadapttotheamountoflightused.Automaticisthedefaultsettinganditcanbe
usedinmostsituations.Theshutterspeedisautomaticallysettoproduceoptimumimagequality.UseManualifyouhavespecial
requirementsfortheexposuresettingandwishtolockit.Selectthedesiredexposuretimefromthedrop-downlist.
Maxexposuretime-Selectthemaximumexposuretimefromthedrop-downlist.Increasingtheexposuretimewillimprove
imagequality,butdecreasetheframerate.Theremayalsobeanincreaseinmotionblur.CheckingAllowslowshutterdecreases
theshutterspeedinlowlighttoimproveimagebrightness.
EnableBacklightcompensation-SelectEnableBacklightcompensationifabrightspotoflight,forexamplealightbulb,causes
otherareasintheimagetoappeartoodark.
HighlightCompensation-TheAxisproductwilldetectabrightlightfromasourcesuchasatorchorcarheadlightsandmaskthat
imagearea.Thissettingisusefulwhenthecameraoperatesinaverydarkareawhereabrightlightmayoverexposepartoftheimage
andpreventtheoperatorfromseeingotherpartsofthescene.
Maxgain-Measuredindecibels(dB),gaindescribestheamountofamplicationappliedtoasignal,inthiscasethevisual
informationintheimage.Ahighlevelofamplicationmayprovideabetterimageinverylowlightsituations.Ahighgainwillalso
increasetheamountofimagenoise.
Exposurezones-Thissettingsdetermineswhichpartoftheimageisusedtocalculatetheexposure.Formostsituations,theAuto
settingcanbeused.Forparticularrequirement,selectapredenedarea.
IRcutlter-TheIRcutlterpreventsinfrared(IR)lightfromreachingtheimagesensor.Inpoorlightingconditions,forexampleat
night,orwhenusinganexternalIRlamp,settheIRcutltertoOff.Thisincreaseslightsensitivityandallowstheproductto“see”
19

Axis Q6045-E Mk II Specifications

General

Type	IP security camera
PTZ control	Yes
Certification	NEMA 4X\\r IK10
Placement supported	Outdoor
Connectivity technology	Wired
Form factor	Dome
Mounting type	Ceiling/wall
Product color	White
Housing material	Aluminum
International Protection (IP) code	IP66
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Video formats supported	H.264, M-JPEG
Supported graphics resolutions	320 x 180, 1920 x 1080 (HD 1080)
Pan range	0 - 360 °
White balance	Auto
Tilt angle range	0 - 220 °
Camera shutter speed	0.000030303 - 0.33 s
Minimum illumination	0.03 lx
Sensor type	CMOS
Optical sensor size	1/2.8 \
Digital zoom	12 x
Optical zoom	32 x
Focus adjustment	1.6 - 4.41
Focal length range	4.44 - 142.6 mm
Security algorithms	HTTPS, SSH, SSL/TLS
Password protection type	User
Built-in HDD	No
Flash memory	128 MB
Internal memory	512 MB
Compatible memory cards	SD, SDHC, SDXC
Cabling technology	10/100Base-T(X)
Supported network protocols	IPv4/v6, HTTP, HTTPS, SSL/TLS, QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP, SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SFTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, NTCIP
Compliance industry standards	PoE IEEE 802.3at
Interface	RJ-45
Ethernet LAN (RJ-45) ports	1
AC input voltage	100-240 V
Power source type	PoE
Storage temperature (T-T)	-50 - 60 °C
Operating relative humidity (H-H)	10 - 100 %
Bundled software	AXIS Camera Companion, \\r AXIS Camera Station, \\r Video management

Weight and Dimensions

Height	280 mm
Weight	3700 g
Diameter	232 mm
