Axis Q6045-E Mk II User Manual

AXISQ6045-EMkIIPTZDomeNetworkCamera
TechnicalSpecifications
Function/group
Item
Specications
Casing
IP66-andNEMA4X-ratedmetalcasing(aluminum),acrylic(PMMA)cleardome,
sunshield(PC/ASA)
Memory512MBRAM,128MBFlash
Batterybacked-upreal-timeclock
Power
HighPoweroverEthernet(HighPoE)IEEE802.3at,max60W
AxisHighPoEMidspan1-port:100–240VAC,max74W
Connectors
RJ4510BASE-T/100BASE-TXPoE
IP66-ratedRJ45connectorkitincluded
Edgestorage
SupportsSDcardswithupto64GBofstorage.Forbestrecordingperformance,usean
SDHCorSDXCcardwithspeedclass10.(cardnotincluded)
Supportforrecordingtonetworkshare(NetworkAttachedStorageorleserver)
ForSDcardandNASrecommendationsseewww.axis.com
Operating
conditions
With30W:-20ºCto50ºC(-4ºFto122ºF)
With60W*:-50°Cto50°C(-58°Fto122°F)
*ArcticTemperatureControlenablescamerastart-upattemperaturesaslowas-50
ºC(-58ºF)
Humidity10-100%RH(condensing)
Storage
conditions
-50ºCto60ºC(-58ºFto140ºF)
Approvals
EN55022ClassA,EN61000-3-2,EN61000-3-3,EN61000-6-1,EN61000-6-2,EN
55024,EN50121-4,IEC62236-4
FCCPart15SubpartBClassA
IECS-003ClassA
VCCIClassA
C-tickAS/NZSCISPR22ClassA
KCCKN22ClassA,KN24
IEC/EN/UL60950-1,IEC/EN/UL60950-22
IEC/EN60529IP66
NEMA250Type4X
IEC60068-2-1,IEC60068-2-2,IEC60068-2-78,IEC60068-2-14,IEC60068-2-30,IEC
60068-2-6,IEC60068-2-27,IEC60068-2-60
ISO4892-2
IEC/EN62262IK10
Midspan:EN60950-1,GS,UL,cUL,CE,FCC,VCCI,CB,KCC,UL-AR
Weight
Camera:3.5kg(7.7lb.)
Included
accessories
AxisHighPoEMidspan1-port,IP66-ratedRJ-45connectorkit,sunshield,Installation
Guide,InstallationandManagementSoftwareCD,Windowsdecoder1-userlicense
Video
management
software
AXISCameraCompanion(included),AXISCameraStationandvideomanagement
softwarefromAxis’ApplicationDevelopmentPartners(notincluded).Formore
information,seewww.axis.com/products/video/software
General
Optional
accessories
Smokeddomecover
AXIST91AMountingAccessories
AXIST8310VideoSurveillanceControlBoard
AXIST90AIlluminators
InstallationDisplay
Multi-userdecoderlicensepack
T81B22DC30WMidspan
63

Axis Q6045-E Mk II Specifications

General

Type	IP security camera
PTZ control	Yes
Certification	NEMA 4X\\r IK10
Placement supported	Outdoor
Connectivity technology	Wired
Form factor	Dome
Mounting type	Ceiling/wall
Product color	White
Housing material	Aluminum
International Protection (IP) code	IP66
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Video formats supported	H.264, M-JPEG
Supported graphics resolutions	320 x 180, 1920 x 1080 (HD 1080)
Pan range	0 - 360 °
White balance	Auto
Tilt angle range	0 - 220 °
Camera shutter speed	0.000030303 - 0.33 s
Minimum illumination	0.03 lx
Sensor type	CMOS
Optical sensor size	1/2.8 \
Digital zoom	12 x
Optical zoom	32 x
Focus adjustment	1.6 - 4.41
Focal length range	4.44 - 142.6 mm
Security algorithms	HTTPS, SSH, SSL/TLS
Password protection type	User
Built-in HDD	No
Flash memory	128 MB
Internal memory	512 MB
Compatible memory cards	SD, SDHC, SDXC
Cabling technology	10/100Base-T(X)
Supported network protocols	IPv4/v6, HTTP, HTTPS, SSL/TLS, QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP, SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SFTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, NTCIP
Compliance industry standards	PoE IEEE 802.3at
Interface	RJ-45
Ethernet LAN (RJ-45) ports	1
AC input voltage	100-240 V
Power source type	PoE
Storage temperature (T-T)	-50 - 60 °C
Operating relative humidity (H-H)	10 - 100 %
Bundled software	AXIS Camera Companion, \\r AXIS Camera Station, \\r Video management

Weight and Dimensions

Height	280 mm
Weight	3700 g
Diameter	232 mm
