Axis Q6100-E Installation Guide

English
Safetyinformation
Hazardlevels
DANGER
Indicatesahazardoussituationwhich,ifnotavoided,
willresultindeathorseriousinjury.
WARNING
Indicatesahazardoussituationwhich,ifnotavoided,
couldresultindeathorseriousinjury.
CAUTION
Indicatesahazardoussituationwhich,ifnotavoided,
couldresultinminorormoderateinjury.
NO NO
NO
TICE TICE
TICE
Indicatesasituationwhich,ifnotavoided,couldresult
indamagetoproperty.
Othermessagelevels
Important
Indicatessignicantinformationwhichisessentialfor
theproducttofunctioncorrectly.
Note
Indicatesusefulinformationwhichhelpsingetting
themostoutoftheproduct.
Safetyinstructions
NO NO
NO
TICE TICE
TICE
•TheAxisproductshallbeusedincompliancewith
locallawsandregulations.
•StoretheAxisproductinadryandventilated
environment.
•AvoidexposingtheAxisproducttoshocksorheavy
pressure.
•Donotinstalltheproductonunstablepoles,
brackets,surfacesorwalls.
•UseonlyapplicabletoolswheninstallingtheAxis
product.Usingexcessiveforcewithpowertools
couldcausedamagetotheproduct.
•Donotusechemicals,causticagents,oraerosol
cleaners.
•Useacleanclothdampenedwithpurewaterfor
cleaning.
•Useonlyaccessoriesthatcomplywiththetechnical
specicationofyourproduct.Thesecanbeprovided
byAxisorathirdparty.Axisrecommendsusing
Axispowersourceequipmentcompatiblewithyour
product.
•Useonlysparepartsprovidedbyorrecommended
byAxis.
•Donotattempttorepairtheproductyourself.
ContactAxissupportoryourAxisresellerfor
servicematters.
•Donotpointthecameralenstowardthesunor
otherhigh-intensityradiationsourcesbecausethis
couldcausedamagetothecamera.
•Thepowersupplyshallbepluggedintoasocket
outletinstalledneartheproductandshallbeeasily
accessible.
•Usealimitedpowersource(LPS)witharated
outputpowerlimitedto≤100Wandaratedoutput
currentlimitedto≤5A.
•Useayellow/greencoloredgroundingcableofat
least2.5mm
2
or12AWG.
Transportation
NO NO
NO
TICE TICE
TICE
•WhentransportingtheAxisproduct,usethe
originalpackagingorequivalenttopreventdamage
totheproduct.
Battery
TheAxisproductusesa3.0VBR/CR2032lithium
batteryasthepowersupplyforitsinternalreal-time
clock(RTC).Undernormalconditionsthisbatterywill
lastforaminimumofveyears.
CAUTION
Donotreplacethebatteryyourself.ContactAxis
supportifthelogmessagerequestsabatterychange.
Lithiumcoincell3.0Vbatteriescontain
1,2-dimethoxyethane;ethyleneglycoldimethylether
(EGDME),CASno.110-71-4.
Domecover
NO NO
NO
TICE TICE
TICE
•Becarefulnottoscratch,damageorleave
ngerprintsonthedomecoverbecausethiscould
decreaseimagequality.Ifpossible,keepthe
protectiveplasticonthedomecoveruntilthe
installationiscomplete.
•Donotcleanadomecoverthatlookscleanto
theeyeandneverpolishthesurface.Excessive
cleaningcoulddamagethesurface.
•Forgeneralcleaningofthedomecoveritis
recommendedtouseanon-abrasive,solvent-free
neutralsoapordetergentmixedwithpurewater
andasoft,cleancloth.Rinsewellwithpure
lukewarmwater.Drywithasoft,cleanclothto
preventwaterspotting.
•Neveruseharshdetergents,gasoline,benzene,
acetone,orsimilarchemicals.
•Avoidcleaningthedomecoverindirectsunlightor
atelevatedtemperatures.
•Makesurethedomeisattachedinoperationmode,
otherwisefocusmaybeaffected.
Français
Informationssurlasécurité
Niveauxderisques
DANGER
Indiqueunesituationdangereusequi,siellen'estpas
évitée,entraîneraledécèsoudesblessuresgraves.
AVERTISSEMENT
Indiqueunesituationdangereusequi,siellen'estpas
évitée,pourraitentraînerledécèsoudesblessures
graves.
ATTENTION

Axis Q6100-E Specifications

General

Form Factor	Dome
Outdoor Ready	Yes
Day/Night Functionality	Yes
Power over Ethernet	Yes
WDR	Yes
IP Rating	IP66
IK Rating	IK10
Sensor Type	1/2.8" Progressive scan CMOS
Minimum Illumination	0.3 lux
Compression	H.264, MJPEG
Network Interface	RJ45 10BASE-T/100BASE-TX
Power Consumption	Max 25 W
