Axis Q8414-LVS - Hardware Overview; Connectors and Buttons

AXISQ8414-LVSNetworkCamera
HardwareOverview
HardwareOverview
12 13
3 10
2
1
114 5 6 7 8 9
1
Cablegasket(networkcable)
2
Cablegasket(I/Ooraudiocable)
3
PoEClassselector*
4
Networkconnector
5
Audiooutconnector
6
LEDindicators
7
Audioinconnector
8
I/Oconnector
9
Controlbutton
10
IRwindow
11
Microphone
12
Notused
13
SDcardslot
*UsedforswitchingbetweenPoEClass2(limitedIR)andPoEClass3(fullIR).
ConnectorsandButtons
Fortechnicalspecications,seepage59.
NetworkConnector
RJ45EthernetconnectorwithPoweroverEthernet(PoE).
