AXIST8504–EOutdoorPoESwitch
Webinterface
ManagementuplinkportThisparameterhasnoeffectonactualVLANtrafc.Themanagementuplinkportassiststhe
unittoevaluateifthenewVLANcongurationmightblocktheunitfrombeingmanaged
overVLANfromthisport.Ifapossibleconictisdetected,anerrormessageappearsandthe
newVLANcongurationisrejected.
ManagementVLANID
CongurewhichVLANIDtobeusedwhenmanagingtheunitwheneverVLANisenabled.
VLANportsconguration
ParameterDescription
VLANmode
SetVLANmodetoAccessorTrunkforeachoftheEthernetports.
Access—VLANisusedonlyinsidetheunittosplitorlimitpacketaccesstospecicports
only.AnyincomingVLANtaggedpacketsreceivedbyVLANaccessportisdiscarded.VLAN
taggingisaddedtotheunitpacketforVLANAccessincomingpackets.UnitinternalVLAN
taggingisstrippedoutforVLANAccessoutgoingpackets.
Trunk—AllEthernetpacketsareVLANtagged.AnyuntaggedVLANpacketsreceivedby
VLANtrunkportisdiscarded.
AccessmodeVLANID
ConguretheVLANIDtobeusedwhenevertheportisconguredasAccess.Theunit
internalmanagementportactsasaccessonly.Itcanonlybereachedfromasingle
managementVLANID.
TRUNK–FilterunknownVLAN
ConguretheVLANTrunkportaslteredorunltered.
Enabled—OnlydataowfromsomeVLANIDs,speciedintheTrunkVLANslist,passes
throughVLANTrunkport.AllotherVLANtaggedtrafcisdiscarded.
Disabled—DataowfromallVLANIDspassesthroughVLANTrunkport.
TRUNKVLANsListtheVLANIDsthatmaypassthroughVLANTrunkportwheneverTRUNK–Filter
unknownVLANisenabled.
SNMPconguration
GotoSNMPcongurationtocongureparametersapplicabletoSNMPv2candSNMPv3.
SNMPv2c
ParameterDescription
EnableSNMPv2cEnableordisableSNMPv2csupport.
Readcommunity
ConguretheSNMPv2cGETcommunitystring.Example:public.
Writecommunity
ConguretheSNMPv2cSETcommunitystring.Example:private.
Trapcommunity
ConguretheSNMPv2cTrapcommunitystring.Example:public.
Systeminformation(MIB-II,v2c/v3)
ParameterDescription
SystemcontactConguretheSNMPMIB-IIsystemcontactOiDstring.Example:John.
SystemnameConguretheSNMPMIB-IIsystemname.Example:MyUnit.
SystemlocationConguretheSNMPMIB-IIsystemlocation.Example:University.
PoEMIB(RFC3621,v2c/v3)
