AXIST8504–EOutdoorPoESwitch
Generalinformation
PCIPv4address:192.168.0.40
PCIPv4mask:255.255.255.0
2.ConnectyourPCEthernetnetworkinterfacetoanyoftheunit’sEthernetports.
3.Openawebbrowserandtype192.168.0.254intheaddresseld.
4.Loginwiththedefaultusernameandpassword.SeeDefaultunitIP,usernameandpasswordonpage6.
5.Conguretheunit.Itisrecommendedtochangetheusernamesandpasswordstootherthanthedefaultvalues.
UnitidenticationoverIPnetwork
TolocatetheunitovertheIPnetwork,theunitsendsIPv4SysLogmessage#0inbroadcastformat255.255.255.255uponpower-up.
AnySysLogserverconnectedoverLANreceivesthisSysLogmessage.ThesameSysLogmessageisalsosenttotheoptionalSysLog
servers1and2,iftheyarecongured.
Theunitsendsthemessagetwice.ThisistoensurethattheSysLogmessageisreceivedbytheSysLogservers,regardlessofnetwork
conguration.ThemessageisrstsentbeforeVLANcongurationismadeandlateragainafterVLANcongurationisdone.
SysLogmessage#0containsalltheinformationwhichisrequiredtobeabletoprovideaccesstotheunitoverthenetwork.
Example:MsgID#000-SystemUP.APP:v3.51.06BOOT:v3.16RST:Power-OnBOOT:0=[APP
OK]Host:axis-00055A034B49MAC:00:05:5a:03:4b:49VLAN:YESVLAN_MNGR:5
VLAN_UPLINK_PORT:3VLAN_UPLINK_MODE:TRUNKDHCPv4:NoIP1v4:192.168.0.254/24DHCPv6:No
IP1v6:2345::205:5AFF:FE03:4B49/64IP2v6:FE80::205:5AFF:FE03:4B49/64
FieldValueDescription
MsgID#000-SystemUP
SysLogmessagenumber
APP:
v3.51.06
Unitapplicationsoftwareversion
BOOT:
v3.16
Unitbootversion,usedforsoftware
update
RST:Power-On
Resetreason
BOOT:
0=[APPOK]
Host:
axis-00055A034B49
axisfollowedbyunitMACaddress
MAC:
00:05:5a:03:4b:49
UnitMACaddress
VLAN:
YES
VLANstatusenabledordisabled
VLAN_UPLINK_PORT:
3
Ethernetportnumberusedforunit
management
VLAN_UPLINK_MODE:
TRUNK
ManagementportisconguredasAccess
orTrunk
DHCPv4:
No
DHCPv4YesorNo
IP1v4:
192.168.0.254/24
UnitIPv4address
DHCPv6:
No
DHCPv6YesorNo
IP1v6:
2345::205:5AFF:FE03:4B49/64
UnitIPv6address
IP2v6:
FE80::205:5AFF:FE03:4B49/64
Unitlink-localIPv6address
